Description
Description
SpectraCool Narrow Hazardous Location Indoor/Outdoor air conditioners are engineered specifically for hazardous location cooling. Attractive design with no heavy cast enclosure and minimal use of visible fasteners. Air conditioners do not require a purge and pressurized system.
Units with Remote Access Control utilize a digital controller and communicate via EtherNet/IP, Profinet, Modbus TCP/IP and SNMP over ethernet or modbus RTU over USB.
Main Features
- Not re-built from light industrial air conditioners
- Painted galvanized sheet metal cover for rugged factory and outdoor environments
- Corrosion resistant coating on ambient side components for Type 4X models
- Corrosion resistant coating on ambient and enclosure side components for Type 4X Offshore models
- Dust resistant coils for filterless operation in most environments
- Cleanable, reusable aluminum mesh filter protects coils for extremely dusty and dirty atmospheres
- Digital temperature control
- Narrow design to accommodate 12-in (300-mm) deep cabinets
- R134a earth-friendly refrigerants
- Models for 115, 230 and 400/460 3-phase VAC power input
- UL Listed to save customers time and money with agency approvals
- Easy-Mount flanges for simple installation
- Standard Type 4/4X models include:
- - Active condensate management with heater strip
- - Compressor Heater
- - Head Pressure Control
- - Malfunction switch
- Nominal cooling capacities:
- - NHZ28 4000 BTU/hr. (1172 W)
- - NHZ36 6000 & 8000 BTU/hr. (1758 and 2344 W)
- - NHZ43 11000 BTU/hr. (3223 W)
- Outdoor model operating temperature range from -40 F/ -40 C to 131 F/ 55 C (125 F/52 C on NHZ28 Series and NHZ43 Series 115V)
Specifications
Specifications
Industry Standards
- UL/cUL Listed; Type 4; 4X; File No. E469720
- CE
- Class 1 Div 2 Groups A, B, C, D T4
Specifications
| Height | 36 in / 914.4 mm |
|---|---|
| Width | 11.5 in / 292.1 mm |
| Depth | 14 in / 355.6 mm |
| Nominal Capacity Btu/h | 8500 Btu/h |
| Nominal Capacity Watts | 2489 W |
| Nominal Voltage | 230 V |
| Voltage AC | 200 V |
| Operating Temperature | -40 to 131 °F / -40 to 55 °C |
| Max Current | 6.2 A |
| Remote Access Control | Yes |
| Material | Mild Steel |
| Color | Light Gray |
| BULLETIN NUMBER | MCLH |
