Hoffman PPTHP2 | ProLine High Performance Exhaust Vent
Regular price
$2,907.71
Unit price
Brand: Hoffman
|
SKU:
654142
Regular price
$2,907.71
Unit price
Description
Description
Vents fit on standard ProLine top with vent cutout or can be field-installed on any ProLine solid top. The Pagoda Vent features an integral centrifugal blower mounted in a housing that includes a drip-proof removable hood, wire mesh finger guard, perimeter gasket and terminal block. Electromagnetic-compatible (EMC) Pagoda Vents include a conductive screen, conductive gasket, line filter and 6-ft. power cord with stripped leads.
Main Features
- Integral centrifugal blower mounted in a protective housing
- Can be installed on any ProLine or ProLine G2 solid top
- Drip-protected, raised cover is removable from the inside of the enclosure
- Housing includes a drip-proof removable hood, wire mesh finger guard and perimeter gasket
- Lead wire or power cord options
- 115V or 230V versions
- Rated UL Type 1; installing this component on an enclosure brings the enclosure rating to UL Type 1
- Installation hardware included
Specifications
Specifications
Specifications
| Material | Mild Steel |
|---|---|
| Voltage AC | 230 V |
| Full Load | 0.9 A |
| Use With | Top with high-performance pagoda vent cutout |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Finish | Powder Coated |
| Thickness | 16 ga / 1.52 mm |
| Weight | 25.5 lb |
| BULLETIN NUMBER | P20 |
