Brand: Hoffman
|
SKU:
10221000
Hoffman PS1060 | Side Plinths, PS, 98x558x27mm, Zinc Plated, Mild Steel
Regular price
$198.35
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Hoffman PS1060 | Side Plinths, PS, 98x558x27mm, Zinc Plated, Mild S...
Regular price
$198.35
Unit price
Description
Description
Hoffman PS1060 | Side Plinths, PS, 98x558x27mm, Zinc Plated, Mild Steel
Side panels to cover the openings in the sides of the PF/PV plinths. Double folded panels for maximum strength. Compatible with combinable and semi-compact enclosure ranges.
Hoffman - PS1060 - Features
- The extra space created by the plinth is closed off by using these panels in order to restrict access to this area.
- Feature: a pair of painted steel plinth side panels to secure single or bayed plinths for mild steel floor standing enclosures
- Advantage: the side panels close the sides of the single or bayed plinths securing the extra space created between the installation floor and enclosure's bottom plates
- Benefit: the side panels protect the extra space created underneath the enclosure
- Comment: side panels can be used to improve the rigidity of bayed plinths however cables cannot pass through them easily, however to optimise the rigidity of the bayed plinths then plinth combining profiles PCP, should be used instead
- BULLETIN NUMBER: FCY
Specifications
Specifications
Hoffman - PS1060 - Product Categories
- Industrial
- Industrial Enclosure Accessories
- IEC Enclosure Accessories
Hoffman - PS1060 - Specifications
| Brand Name | Hoffman |
|---|---|
| Manufacturer Part Number | PS1060 |
| Item Description | Side Plinths, PS, 98x558x27mm, Zinc Plated, Mild Steel |
| Height | 3.86 in / 98 mm |
| Width | 21.97 in / 558 mm |
| Depth | 1.04 in / 27 mm |
| Material | Mild Steel |
| Finish | Powder Coated |
| Color | Umbra Gray |
| Color Code | RAL 7022 |
| Thickness | 16 ga / 1.5 mm |
| Package Quantity | 2 |
| Weight | 4.52 lb |
