Brand: Hoffman
|
SKU:
9810204
Hoffman T303020FTTXDA | FTTX Fiber Optic Cabinet Package, Type 4X, 30x30x20, Lt Gray, Al, Dual
Regular price
$5,489.45
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Hoffman T303020FTTXDA | FTTX Fiber Optic Cabinet Package, Type 4X, ...
Regular price
$5,489.45
Unit price
Description
Description
Pad-mounted FTTX welded aluminum enclosures provide longlasting protection and manage fiber optic cable for broadband delivery in outdoor applications. Provided with or without back-up batter compartment.
Main Features
- Standard pitched roof promotes water runoff
- Available with either single- or dual-access doors on front and rear for convenient access
- Available with or without battery compartment
- 3-point latching mechanisms and padlocking handles on doors provide security
- Seamless foam-in-place gasket seals doors against moisture and dust
- Wind latch mechanisms on doors control door when open for equipment maintenance
- Removable lifting lugs (2) for easy installation
- Rack angles adjustable for 19- or 23-inch spacing without modifications
- Use cage nuts to mount equipment
- Cabinet top insulation helps prevent the formation of condensation and reduce solar gain inside cabinet. Cabinet side insulation is optional
- Base of cabinet has a 5.00-inch (127-mm) high aluminum mounting plinth to allow for cable alignment
- Three pyramidal boots provided at base of cabinet for sealing various sizes of cables
- All fasteners are stainless steel to maintain professional appearance in severe outdoor climate conditions
Specifications
Specifications
Industry Standards
- UL 508A Listed; Type 3, 3R, 4, 4X, 12; File No. E61997
- CSA: Type 3, 3R, 4, 4X, 12
- NEMA/EEMAC Type 3, 3R, 4, 4X, 12
- EC60529, IP66
- Designed to meet Telcordia NEBS GR-487, GR-63 and IEC 48D
Specifications
| Height | 30 in / 762 mm |
|---|---|
| Width | 30 in / 762 mm |
| Depth | 20 in / 508 mm |
| Protection Rating | NEMA Type 12; NEMA Type 4; NEMA Type 4X; IP66 |
| Material | Aluminum |
| Finish | Powder Coated |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Thickness | 0.125 in / 3 mm |
| Rack Units | 10 |
| Weight | 120 lb |
| BULLETIN NUMBER | DTX |
