Brand: Inaxsys Security Systems
|
SKU:
10013535
Inaxsys Security Systems DT-IPS-H-20T | High Performance Desktop IP Server, 20000 GB Hard drive
Regular price
$8,407.76
Unit price
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Inaxsys Security Systems DT-IPS-H-20T | High Performance Desktop IP...
Regular price
$8,407.76
Unit price
Brand: Inaxsys Security Systems
|
SKU:
10013535
Regular price
$8,407.76
Unit price
Description
Description
Inaxsys Security Systems DT-IPS-H-20T | High Performance Desktop IP Server, 20000 GB Hard drive
Parts / Vendor ONLY sold in Canada and to Canadian Certified Customers.
Inaxsys Security Systems - DT-IPS-H-20T - Features
- The Desktop Case IP Server is a high-performance solution designed for robust video management and storage. Powered by the latest generation Intel® Core i7 Processor, this server offers exceptional processing capabilities. It features a 1TB M.2 NVMe boot drive and an additional 1TB NVMe SSD for swift data access and storage.
- Equipped with 16GB of DDR-5/4800 memory (2 x 8GB), the server ensures smooth multitasking and efficient operation. With a storage capacity of up to 64TB, it is well-suited for extensive data retention needs. The server supports a range of video management software, including Arkiv, STORM, LEGEND, and third-party applications like ExacqVision™, Genetec™, Milestone™, and Avigilon™.
- Ideal for comprehensive IP surveillance solutions, this server combines power, flexibility, and extensive compatibility to meet diverse security and monitoring requirements.
Specifications
Specifications
Inaxsys Security Systems - DT-IPS-H-20T - Product Categories
- Security
- Video Surveillance
- Video Servers and Storage
Inaxsys Security Systems - DT-IPS-H-20T - Specifications
| Brand Name | Inaxsys Security Systems |
|---|---|
| Manufacturer Part Number | DT-IPS-H-20T |
| Item Description | High Performance Desktop IP Server, 20000 GB Hard drive |
| Hard Drive Type | Sata |
| Type | Server |
| Mount Type | Desktop |
| Operating System | Windows |
| UNSPSC Code | 46171600 |
| Disk space | 20 TB |
| Raid | - |
| Hot swap | - |
| Dual supply | - |
| Maximum IP Cameras | Data rate dependent; VMS Application dependent |
| Video Management Software | Arkiv, STORM, LEGEND or 3rd party software such as ExacqVision™, Genetec™, Milestone™, Avigilon™, and more |
| Server OS | Windows 11 Pro 64 bit (standard) |
| Maximum storage | 64 TB |
| Drive Bays | 4 x 3.5” SAS/SATA Backplane for Hot-Swappable Drives |
| DVD / CD-ROM | Optional |
| Keyboard & Mouse | Included |
| Network Controllers | Dual LAN with Intel® Ethernet i225LM |
| LAN | PCIE Network Card (Startech ST1000SPEX2L GbE, TP-Link TG-3468, or equivalent) |
| SATA | Intel Q670E controller for 8 SATA3 (6 Gbps) ports; |
| PCI-E Add on Card | Up to 2 NVMe SSDs |
| Graphics Adapter | NVIDIA A2000 |
| CPU | Latest Generation Intel®Core i7, 30M Cache, up to 5.20 GHz |
| Core | Up to 24 cores |
| Solid-State Drive | 2 x 1TB NVMe M.2 |
| *Maximum Video Storage Rate | 600 to 800 Mbps (Windows) |
| RAM | 2 x Memory 8GB DDR-5/4800 (or faster) |
| Memory Type | 4400/4000/3600 MT/s |
| DIMM Sizes | 4GB, 8GB, 16GB, 32GB |
| Memory Voltage | 1.1V |
| USB Ports | 6 x USB 2.0 & 6 x USB 3.1 |
| Display Outputs | 1 VGA port, 1 HDMI port, 1 DP (DisplayPort) port, 1 DVI - D port |
| SATA | 8 SATA3 (6Gbps) port(s) |
| Input Voltage | 668W with Input 100 - 240Vac |
| Power supply | PS2 668W Multi-output power supply 80PLUS Platinum |
| Heatsink/Fan | Speed Control: 4-pin PWM; Rated Voltage: 12.0 VDC; Rated Speed: 3,800 RPM |
| Dimensions | 426 mm x 178 mm x 531 mm (H x W x D) |
| Weight | 40 lbs |
| Regulatory | BSMI; CCC; CE/EMC; FCC class B; TUV/CB; UL/CUL |
