Description

Inaxsys Security Systems INS8824KN14T | 8-Channel 4K NVR/8 POE with 14TB

Parts / Vendor ONLY sold in Canada and to Canadian Certified Customers.

Inaxsys Security Systems - INS8824KN14T - Features

The 8-Channel 4K NVR with 8 PoE ports is a powerful, all-in-one solution for efficient and intelligent video surveillance. With H.265+ and H.264+ smart decoding, this NVR optimizes storage and bandwidth, supporting a high incoming bandwidth of up to 384 Mbps and delivering impressive 24MP resolution for both preview and playback.
Equipped with AI on the edge, this NVR enhances security capabilities through advanced features like Area Protector, Face Recognition, Heat Mapping, People Counting, and Smart Motion Detection. Its 8 PoE ports offer seamless integration with IP cameras, making installation straightforward and versatile.

Specifications

Inaxsys Security Systems - INS8824KN14T - Product Categories

Security
Video Surveillance
Video Recorders

Inaxsys Security Systems - INS8824KN14T - Specifications

Brand Name	Inaxsys Security Systems
Manufacturer Part Number	INS8824KN14T
Item Description	8-Channel 4K NVR/8 POE with 14TB
Capacity	8 Channel
Audio	Yes
Mount Type	Desktop
Type	Nvr
UNSPSC Code	46171621
Disk space	14 TB
UPC	685225602958
Raid	Unequiped
Main Processor	Quad-core embedded processor
Operating System	1 HDMI, 1 VGA
Operation Interface	Web; GUI local
Area Protector	Performance of AI by Camera 8 channels
Performance AI by Recorder	4 channels
Area Protector AI Search	Search for pictures by channel, time and event type
Face Recognition Performance	Up to 8 channels
Face Attributes	Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
Face Recognition AI Search	Search for pictures by channel, time and face attributes
Smart Motion Detection Performance	8 channels
mart Motion Detection AI Search	Search by target classification (Human, vehicles).
Video Metadata Performance	8 channels
Human Detection	Clothes color; Hat; Bag; Age; Gender
Vehicle Detection	License Plate number; Type of vehicle; Color; Region
Video Metadata AI Search Performance	Supports searching for target video by metadata
License plate recognition Performance	8 channels
Stereo Analysis Performance	8 channels
Video Channels	8 channels
Network Bandwidth	AI disabled: 384 Mbps for access, 384 Mbps for storage and 384 Mbps for forwarding
AI enabled	200 Mbps for access, 200 Mbps for storage and 200 Mbps for forwarding
Resolution	32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF
Decoding Capability	Up to 8-channel at 8MP (30 fps)
Video Output	HDMI1: 3840 × 2160; 1920 × 1080; 1280 × 1024; 1280 × 720 VGA1: 1920 × 1080; 1280 × 1024; 1280 × 720
Multi-screen Display	8-channel: 1 / 4 / 8 / 9
Third Party Camera Access	Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon and more
Video Compression	H.265+; H.264+; H.265; H.264; MJPEG
Audio Compression	PCM; G.711A; G.711U; G.726
Network Protocol	HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Supports STORM IP cameras, DVR, NVR, and more.); P2P
Mobile Phone Access	Android; iOS
Interoperability	ONVIF (profile T/S/G); CGI; SDK
Multi-channel Playback	Up to 8 channels
Record Mode	Manual; schedule (general; MD; alarm; MD & alarm; intelligent; POS)
Backup	USB device
Playback Function	Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection)
Alarm General	Motion detection; privacy masking; video loss; local alarm
Anomaly	Offline cameras; storage error; full storage; IP conflict; MAC conflict; login locked; network security anomaly
Smart Alarm	Area Protector; face detection; face recognition; smart motion detection; video metadata (human; motor vehicles; non-motor vehicles); license plate recognition; people counting; stereo analysis; heat map
Alarm Linkage	Record; snapshot; IPC external alarm output; buzzer; log; preset; email
Port Audio Input	1 channel, RCA connector
Audio Output	1 channel, RCA connector, which supports voice intercom output
HDD	2 SATA III ports, up to 16 TB for a single HDD. The maximum HDD capacity varies with environment temperature
Alarm Input	4 channels
Alarm Output	2 channels
RS-232	1 channel, used to debug and pass through serial data
RS-485	1 channel, used to control PTZ, and it supports multiple protocols
USB	1 front USB 2.0 port, 1 rear USB 3.0 port
HDMI	1
VGA	1
Network	1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet port
PoE	8 ports (IEEE802.3af/at)
General Certifications	FCC: 47 CFR FCC Part15, SubpartB, Class A; CE-EMC: EN 55032: 2015+A1: 2020; EN IEC 61000-3-2: 2019+A1: 2021; EN 61000-3-3: 2013+A1: 2019+A2: 2021; EN 55035: 2017+A11: 2020; EN 50130-4:2011+A1: 2014; CE-LVD: EN 62368-1: 2014
Power Supply	Single, 100V–240V AC, 43 Hz–63 Hz; Less than 10 W without HDD PoE: Max 25.5W for single port 130W total rated power, 80% control for protection
Weight	5.67 lbs (2.57kg)
Dimensions	375.0 mm × 329.4 mm × 53.0mm (14.8” × 12.9” × 2.1”)
Operating Temperature	10°C to +55°C (+14°F to +131°F); 10%–93% (RH)
