Inaxsys Security Systems INSWDO2IRWCF | 2.1MP 1080P HDCVI Wedge Camera With IR, 120Db, Audio
Regular price
$169.56
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Inaxsys Security Systems INSWDO2IRWCF | 2.1MP 1080P HDCVI Wedge Cam...
Regular price
$169.56
Unit price
Brand: Inaxsys Security Systems
|
SKU:
753886
Regular price
$169.56
Unit price
Shipping calculated at checkout.
Description
Description
Inaxsys Security Systems INSWDO2IRWCF | 2.1MP 1080P HDCVI Wedge Camera With IR, 120Db, Audio
Inaxsys Security Systems - INSWDO2IRWCF - Features
- The 2.1MP 1080P HD over Coax Wedge Camera combines high-definition surveillance with durable construction for versatile security applications. Powered by a 2-megapixel progressive CMOS sensor, this camera provides clear 1080P video at 30 fps and offers both HD and SD dual-output, making it adaptable to various system requirements.
- Featuring True Wide Dynamic Range (WDR) of 130dB, it ensures balanced lighting in challenging conditions, capturing clear details in both bright and dark areas. With an IR range up to 30 meters, IP67 weatherproofing, and IK10 impact resistance, this wedge camera is designed to deliver reliable performance and resilience in any environment.
Specifications
Specifications
Inaxsys Security Systems - INSWDO2IRWCF - Product Categories
- Security
- Video Surveillance
- Surveillance Cameras
Inaxsys Security Systems - INSWDO2IRWCF - Specifications
| Brand Name | Inaxsys Security Systems |
|---|---|
| Manufacturer Part Number | INSWDO2IRWCF |
| Item Description | 2.1MP 1080P HDCVI Wedge Camera With IR, 120Db, Audio |
| UNSPSC Code | 46171600 |
| UPC | 685225604983 |
| Image Sensor | 1/2.7” progressive scan CMOS 2.1 Megapixel |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/25 s–1/100,000 s NTSC: 1/30 s–1/100,000 s |
| Minimum Illumination | 0.001 Lux/F1.6, 30 IRE, 0 Lux IR on |
| S/N Ratio | More than 65 dB |
| IR Distance | Up to 30 m (98.4 ft) |
| IR LEDs | 8 |
| Day/Night | Auto (ICR) / Manual |
| Backlight Compensation | BLC / HLC / WDR 130dB |
| White Balance | Auto/Manual |
| Gain Control | AGC |
| Noise Reduction | 3D NR |
| Smart IR | Auto / Manual |
| Privacy Masking | Lens |
| Lens Type | Fixed |
| Mount Type | Board-in |
| Focal Length | 2.8mm |
| Max. Aperture | F1.6 |
| Viewing Angle | H: 109°; V: 58°; D: 127° |
| Pan / Tilt / Rotation | Pan: -30° to 30°; Tilt: 0° to 80°; D: 0° to 360° |
| DORI Distance | Detect: 42.2 m (138.5 ft); Observe: 16.9 m (55.4 ft); Recognize: 8.4 m (27.6 ft); Identify: 4.2 m (13.8 ft) |
| Video Frame Rate | 1080P at 25/30fps; 720P at 25/30fps; 720P at 50/60fps; AHD: 1080P at 25/30fps; 720P at 25/30fps; TVI: 1080P at 25/30fps; 720P at 25/30fps; 720P at 50/60fps; CVBS: 960H |
| Resolution | 1080p (1920 × 1080); 960H (960 × 576 / 960 × 480) |
| Audio Interface | Built-in Microphone |
| Video output | ?hoices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch) |
| Power Supply | 12V ±30% DC |
| Power Consumption | Less than 2.7W |
| Working Environment | -40°C to +60°C (-40°F to +140°F); Less than 95% RH |
| Protection | IP67; IK10 |
| Dimensions | ?106 mm × 50.3 mm (?4.17” × 1.98”) |
| Weight | 0.97 lb (0.59kg) |
