Typically used where flexibility, strength, and low weight is required, Kynar® wire is ideally suited in wire wrap, power supply, medical, and aerospace applications. Additionally, Kynar insulation provides excellent mechanical properties over a large temperature range and is resistant to an extensive range of chemicals including most inorganic and organic acids, bases, alcohols, halogenated solvents, and aliphatic & aromatic hydrocarbons
Jonard - R30R-1000 - Features
- OHFC (oxygen-free high conductivity) silver-plated copper conductor provides exceptional electrical conductivity and flexibility
- Kynar® insulation provides high temperature resistance (up to 105°C) and excellent abrasion resistance
- Meets or exceeds UL 1423 standards
Specifications
Specifications
Jonard - R30R-1000 - Specifications
| Manufacturer Part Number | R30R-1000 |
|---|---|
| Manufacturer | Jonard |
| Item Description | 30 AWG Kynar® Wire, Red, 1000 ft |
| Insulation Type | Kynar® |
| Insulation Thickness | 0.005" (0.127 mm) |
| Wire Gauge | 30 AWG (0.25 mm) |
| Overall Diameter | 0.020" (0.50 mm) |
| Voltage | Not Rated |
| Reel Length | 1000 ft. (304.8 meters) |
| Standards | UL 1423 |
| Voltage | Not Rated |
| Dimensions | 2 in x 2 in x 2 in (5.08 cm x 5.08 cm x 5.08 cm) |
| Weight | 0.53 lb (240.62 g) |
| UPC # | 811490012752 |
