Klein Tools KT4600 | Parallel Jaw Grip 4600 Series
Regular price
$276.95
Unit price
Brand: Klein Tools
|
SKU:
522544
Regular price
$276.95
Unit price
Description
Description
Klein Tools KT4600 | Parallel Jaw Grip 4600 Series
Lightweight, compact grips pull an exceptionally wide range of cable sizes and types. Designed with a round serrated jaw to firmly grip insulated cables and conductors. A hot latch closed automatically to guard against grip accidently disengaging from wire. A large opening in the handle accommodates a wide variety of hooks on hoists, winches and tackle blocks.
Klein Tools - KT4600 - Features
- Versatile grip hold a wider range of ACSR cable sizes reducing the number of grips needed
- Round jaw holds 0.30 to 0.80-Inch (7.62 to 20.30 mm) diameter cable range
- Large opening in the handle accommodate a wide variety of hooks on hoists, winches and tackle blocks
- Max Safe Load of 10,000-Pound (4536 kg)
- Made in USA
Specifications
Specifications
Klein Tools - KT4600 - Product Categories
- Shop by Manufacturer/Klein Tools
- Hardware and Supplies
- Tools and Supplies
- Cable Installation Tools
- Wire Pulling Grips
- Parallel Jaw Grips
Klein Tools - KT4600 - Related Products
- KT4500 - Parallel Jaw Grip 4500 Series for ACSR
- KT4501 - Parallel Jaw Grip 4501 Series with Hot Latch
- KT4502 - Parallel Jaw Grip 4502 Series with Hot Latch
- KT4601 - Parallel Jaw Grip 4601 Series with Hot Latch/Spring
- KT4602 - Parallel Jaw Grip 4602 Series with Hot Latch
Klein Tools - KT4600 - Accessories
- 25450 - Grip-Cleaning Brush Set
Klein Tools - KT4600 - Specifications
| Type | Parallel Jaw Grip |
|---|---|
| Application | Firmly Grip Insulated Cables and Conductors |
| Special Features | Spring |
| Overall Length | 13'' (33 cm) |
| Overall Height | 1.5'' (3.8 cm) |
| Overall Width | 5'' (12.7 cm) |
| Cable Type | ACSR, AAC, Copper |
| Cable Diameter | 0.3'' to 0.8'' (7.62 to 20.3 mm) |
| Swing Latch | N |
| Spring | Y |
| Locking Handle | N |
| Jaw Type | Round - Serrated |
| Jaw Length | 5'' (12.7 cm) |
| Maximum Safe Load | 10,000 lb (4536 kg) |
| Hot Latch | N |
| Weight | 7.0 lb (3.2 kg) |
| UPC | 092644477539 |
| Warranty | https://www.kleintools.com/content/warranty-product-group |
| Warnings | Before each use, clean jaw area and inspect grip for proper operation to avoid slippage. When used on/near energized lines, ground, insulate, or isolate grip before pulling. Do Not exceed rated capacity. Always match proper size and type of grip to application. Grips are to be used for temporary installation, Not for permanent anchorage. |
Klein Tools - KT4600 - Videos
| Klein Tools KT4600 Video | Click to View |
|---|
