Lantronix C3221-1040 | ION Gigabit Ethernet Remotely Managed NID Module10/100/1000Base-T to 1000Base-X with OAM/IP-Based Management
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Lantronix C3221-1040 | ION Gigabit Ethernet Remotely Managed NID Mo...
Description
Description
The ION C3220 is a managed Network Interface Device (NID) module that provides an interface between 10/100/1000Base-T ports and 1000Base-SX/LX ports, allowing users to manage their links while integrating fiber optic cabling into 10/100/1000 copper environments. As a remotely managed device, the C3220 can be managed individually via an IP address or it can be managed by the ION Management Module when installed in a managed ION chassis. With advanced features like IEEE 802.3ah Link OAM, VLAN, QoS, SSH/SSL, jumbo frame support, and bandwidth allocation, the C3220 provides various methods for secure delivery of Ethernet services in business and mobile backhaul applications.
Lantronix - C3221-1040 - Features
- MEF 9, 14 and 21 certified
- IEEE 802.3ah Link OAM
- 10K Jumbo Frame Support
- Two selectable Remote Management modes:
- IP-Based Remote Management
- In-Band (remote device managed by local peer)
- Auto-MDI/MDIX
- Auto-Negotiation
- Pause
- Transparent Link Pass Through
- Far-End-Fault (FEF)
- Remote Loopback
- Field Upgradeable Firmware
- IEEE 802.1p QoS packet classification
- IPv4 IP TOS, DiffServ and IPv6 traffic class QoS classification
- IEEE 802.1Q VLAN and double VLAN tagging with 4096 VIDs
- DHCP client
- SNTP
- TFTP
- RADIUS client
- RMON counters for each port
- Bandwidth profiling
- DMI Optical Management
- Cable diagnostic function for copper ports
- SSH
- Telnet
- Command Line Interface (CLI)
- Web management
- Focal Point Management
- SNMP v1, v2c, and v3
- USB port for basic setup
- Management VLAN
Specifications
Specifications
Lantronix - C3221-1040 - Specifications
| Device | Media Converters |
|---|---|
| Port 1 Device Technology | 10/100/1000BASE-TX |
| UNSPSC Code | 43201553 |
| Data Rate | Copper: 10/100/1000 Mbps; Fiber: 1000 Mbps |
| Max Frame Size | 10,240 bytes |
| Width | 0.86" [22 mm] |
| Depth | 6.5" [165 mm] |
| Height | 3.4" [86 mm] |
| Power Consumption | 4.5 Watts |
| Operating | 0°C to 50°C |
| Humidity | 5% to 95% (non-condensing) |
