Lantronix N2EATLAS60107NA | Multi-service Switch, Atlas Cpe With (4) Rj-45 (1) Empty Sfp Cage Quectel Ec25-mx Lte Modem And Na Power Cord
Regular price
$677.83
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Lantronix N2EATLAS60107NA | Multi-service Switch, Atlas Cpe With (4...
Regular price
$677.83
Unit price
Description
Description
Lantronix ’ Net2Edge ATLAS Series CPE is a fully cased, mains powered, stand-alone CPE device, offering LTE failover and backup. The ATLAS operates at full bandwidth (1Gbps bidirectional) on a single fiber link, supporting up to (4) 10/100/1000Base-T RJ-45 ports, and (1) 100/1000Mbps fiber SFP slot. The integrated LTE modem supports a single SIM card (not provided) and can be used for optional data failover. Other use cases are rapid deployment ahead of fiber roll-out.
Key Features
- Management over LAN, WAN or LTE (L2TPv3 session)
- Static Unmanaged L2TPv3 Ethernet Pseudowire
- Dual L2TP server
- Management VLAN on any copper or fiber port
- IPv4 management support
- VLAN (IEEE 802.1Q) Q-in-Q (C-Tag)
- Syslog
- 4K VLANS
- Auto-Negotiation
- Forced speed/duplex modes
- Full duplex / flow control
- Loop Protection
- Traffic limiting by interface
- 2000 byte Jumbo frames over Ethernet ports
- Static Routing
- Bidirectional Forwarding Detection (BFD)
- Linux based software stack
- Netconf
- QoS support on both port and logical interfaces
- Ingress and egress rate limiting per port
- TACACS+ & ACL
- Remote firmware upgrades
- LLDP
- Generic storm controllers for flooded broadcast, flooded multicast, and flooded unicast traffic
- Static IP and DHCP client support
- Read-only device config/status support via SNMP v2c and V3
- SSHv2
- NTP server syncing
- AAA accounting
- Front Panel LED for configurable alarms
- Supports OTDR capture from OTDR SFPs
- Additional features may be available by request
Specifications
Specifications
Specifications
| Standards | IEEE 802.3 IEEE 802.3ad IEEE 802.1Q IEEE 802.3u IEEE 802.3z IEEE 802.3x IEEE 802.1p IEEE 802.1AB |
|---|---|
| Ports | (4) 10/100/1000Mbps Base-T ports (1) 100/1000Mbps SFP slots (1) RJ-45 Management ports |
| Dimensions | Width: 8.58" [218 mm] Depth: 7.48” [190 mm] Height: 1.73” [44 mm] |
| Power Input | 100 - 240VAC (0.1A max) |
| Power Consumption | 20 Watts |
| Environment | Operating: 0°C to 55°C Storage: -20°C to 65°C |
| Weight | 2.31 lbs. [1.05 kg] |
| Certifications | FCC Part 15B ETSI EN 301 511 V12.5.1 (2017-03) ETSI EN 301 908-1 V11.1.1 (2016-07) ETSI EN 301 908-13 V11.1.2 (2017-07) ETSI EN 301 908-2 V11.1.2 (2017-08) ETSI EN 301 489-1 V2.2.3 (2019-11) ETSI EN 301 489-52 V1.1.0 (2016-11) EN 62311:2008 |
| Warranty | 1 Year |
