Brand: Lantronix
|
SKU:
10129780
Lantronix NM2GXE2230LC201 | M.2 Nic And Mm LC Media Converter, 30mm
Regular price
$410.70
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Lantronix NM2GXE2230LC201 | M.2 Nic And Mm LC Media Converter, 30mm
Regular price
$410.70
Unit price
Description
Description
Lantronix M.2 Gigabit Ethernet Fiber Network Interface Card (NIC) provides a fiber optic interface for the Dell OptiPlex 3060/5060/7060/7070 and 7080/7090 Micro PCs. The NM2-GXE-2230-xx-201 Series consists of a M.2 NIC that installs into the OptiPlex Micro PC’s M.2 “A or E keyed” interface, a fiber optic adapter that installs into the OptiPlex Micro PC’s Option port, and a 20-pin Flat Flex Cable (FFC) that connects the NIC to the fiber adapter. The fiber optic adapter is available with either a 1000Base-SX LC connector or an open SFP (SFP module sold separately). Please note the variation in versions within Ordering Information.
Key Features
- PCI Express M.2 compliant
- A + E keyed M.2 interface
- Full duplex
- Flow control
- Wake on LAN (WOL)
- Smart Load Balancing (SLB)
- TCP Segmentation Offload (TSO)
- Message Signaled Interrupts (MSI)
- Extended Message-Signaled Interrupts (MSI-X)
- LACP support (Teaming)
- IPv6 Capable
- Supports UEFI
- Supports PXE boot
- Jumbo frame support 9014 bytes
- 1000Base-X open SFP interface
Specifications
Specifications
Specifications
| Standards | IEEE 802.3-2012 |
|---|---|
| Bus Slot | M.2 - ‘2230-D4-A-E’ |
| Data Rate | 1000 Mbps (full duplex only) |
| Max Frame Size | 9014 bytes |
| Status LEDs | LINK/ACT ON = Link Flashing = Activity |
| Dimensions (M.2 NIC) | 2230-D4-A-E Width: 0.87” [22 mm] Depth: 1.18” [30 mm] Height: 0.12” [3.08 mm] |
| Dimensions (Fiber Interface) | Width: 1.65” [42 mm] Depth: 2.05” [52 mm] Height: 0.51” [13 mm] |
| Dimensions (FFC Cable) | NM2-GXE-2230-xx-201: Length 5.013” [127.33 mm] NM2-GXE-2230-xx-201A: Length 4.911” [124.74 mm] |
| Software Support | Windows 10, 8, 8.1, and 7 (32/64 bit); Linux |
| Power Consumption (LC) | 250mA @ 3.3V (0.8 Watts typical) |
| Power Consumption (SFP) | 120mA @ 3.3V (0.4 Watts typical without SFP module) |
| Power Source | M.2 interface connector: 3.3V (Refer to table 41 of M.2 Specification) |
