Legrand 8300HRED | Hospital Grade Duplex Receptacle, 20A, 125V, Red
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Description
Description
When it comes to toughness, this no-compromise receptacle has it all, impact-resistant nylon face and body, heavy-gauge brass strap locked into both the body and face and one-piece, triple wipe, nickel-plated brass contacts. It also features screw-pressure-plate back wiring on all terminals (including the ground) for the fastest installation. Circuit label on the face and LED lamps on illuminated face models add value.
Legrand - 8300HRED - Features
- Impact-resistant nylon face.
- .032 inch thick, brass, triple-wipe power contacts for lasting retention.
- Easily accessible break-off line contact connecting tab for split circuit wiring.
- Corrosion-resistant, zinc-plated steel strap is locked in.
- Internal screw-pressure-plate back wire and side wire line terminals accept #14 : #10 AWG copper or copper-clad conductors.
- High strength thermoplastic back body.
- Auto-ground clip assures positive ground.
- Compact design for easy installation.
- Tri-drive terminal and mounting screws.
- Temperature Rise: Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60°C, minimum -40°C without impact
Specifications
Specifications
Legrand - 8300HRED - Specifications
| Manufacturer part number | 8300HRED |
|---|---|
| Brand Name | Legrand |
| Item Description | Hospital Grade Duplex Receptacle, 20A, 125V, Red |
| Amperage | 20A |
| Application Grade | Hospital |
| Color | Red |
| Contact Material | Brass |
| Ground | Grounding |
| Height | 3.28 in. |
| Length | 1.32 in. |
| Material | Thermoplastic |
| NEMA Configuration | NEMA 5-20R |
| Number of Poles | 2P |
| Number of Wires | 3 |
| Product Type | Heavy-Duty Hospital-Grade Compact Straight Blade Receptacle |
| Strap Material | Steel |
| Tamper Resistant | No |
| Temperature Rating | -40 to +60 C |
| Terminal Type | Wire |
| Type | Duplex, Slim Design |
| Voltage | 125V AC |
| Waterproof | No |
| Weather Resistant | No |
| Width | 0.78 in. |
| Wire Size - Maximum | 4 AWG |
| Wiring Method | Back, Side |
