Brand: Ortronics
|
SKU:
1003990
Legrand - Ortronics M4LCD12-09S1A1 | Momentum 2 Series, M4 Splice Cassette, 12-Fiber, Singlemode - OS2, LC Duplex, 1 RU, Rack Mount, Blue
Regular price
$564.53
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Legrand - Ortronics M4LCD12-09S1A1 | Momentum 2 Series, M4 Splice C...
Regular price
$564.53
Unit price
Description
Description
Legrand - Ortronics M4LCD12-09S1A1 | Momentum 2 Series, M4 Splice Cassette, 12-Fiber, Singlemode - OS2, LC Duplex, 1 RU, Rack Mount, Blue
These high-density splice cassettes fit within the M4 drawer face and enable fast field termination and providecable management within the cassette housing.
Ortronics M4LCD12-09S1A1 Main Features
- The cassettes feature a laser cleaved pigtail from the factory and support fusion splicing of individual or
- ribbon fibers, with heat shrinks, pigtail slack, and cable slack managed within the cassette itself.
- Individual fibers within the cassette may be accessed without disturbing the other fibers in the housing
- Mounts from either the front or rear of the enclosure or panel
- Manages fibers within the enclosure
- Tier 1 performance characteristics for insertion and return loss
Specifications
Specifications
Ortronics M4LCD12-09S1A1 Additional Information
- RoHS Conformant: Yes
Ortronics M4LCD12-09S1A1 Specifications
| Type | SPLICE MODULE |
|---|---|
| UNSPSC Code | 43223300 |
| ECCN | EAR99 |
| Country of Origin | CN - China |
| Series | Momentum 2 Series |
| Color | Blue |
| Adapter Type | LC Duplex |
| Module Size | 1 |
| Connector Type | LC |
| Fiber Count | 12 |
| UPC Number | 662875011828 |
| Country Of Origin | China |
| Product Line | Legrand |
| Application Sector | Commercial |
| Type | Cassette |
| Standard | TIA-568-C.3 |
