Brand: Leviton Manufacturing Co
|
SKU:
10657256
Leviton 2316 | NEMA L5-20R Locking Flanged Receptacle, 20A, 125V
Regular price
$49.20
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Leviton 2316 | NEMA L5-20R Locking Flanged Receptacle, 20A, 125V
Regular price
$49.20
Unit price
Brand: Leviton Manufacturing Co
|
SKU:
10657256
Regular price
$49.20
Unit price
Shipping calculated at checkout.
Description
Description
Leviton 2316 | NEMA L5-20R Locking Flanged Receptacle, 20A, 125V
LEV 2316 FLANGED-OUTLET
Specifications
Specifications
Leviton - 2316 - Specifications
| Manufacturer part number | 2316 |
|---|---|
| Brand Name | Leviton Manufacturing Co |
| Item Description | NEMA L5-20R Locking Flanged Receptacle, 20A, 125V |
| Amperage Rating | 20 A |
| Amperage | 20 |
| Application | Commercial |
| Color | White |
| Current Rating | 20 A |
| Fire Rating | Rated V-2 Per UL 94 |
| Ground | Grounding |
| Grounding | Grounded |
| Material | Nylon |
| Mounting | Flange |
| NEMA Configuration | L5-20R |
| NEMA Rating | L6-20R |
| NEMA | L5-20R |
| Number of Poles | 2 Poles |
| Number of Wires | 3 Wires |
| Operating Temperature - Maximum | 60 |
| Operating Temperature - Minimum | -40 |
| Product Type | Locking Outlet |
| Size | 2.50 Dia x 1.78 H IN |
| Special Rating | ANSI : C-73; CSA C22.2 No. 42 : File LR-406; NEMA : WD-6; NOM : 057; UL Fed Spec WC-596 : File E13393; UL498 : File E13393 |
| Temperature Rating | -40 to +60 DEG C |
| Torque | 10 to 14 |
| Voltage | 125 |
| Wire Size - Maximum | 10 |
| Wire Size - Minimum | 18 |
