Brand: Leviton Manufacturing Co
|
SKU:
9997545
Leviton 5306M-2S5 | 20 Amp (16 Amp Max Continuous Load) 125VAC, Medical Grade Surge Protective Power Strip
Regular price
$326.05
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Leviton 5306M-2S5 | 20 Amp (16 Amp Max Continuous Load) 125VAC, Med...
Regular price
$326.05
Unit price
Brand: Leviton Manufacturing Co
|
SKU:
9997545
Regular price
$326.05
Unit price
Shipping calculated at checkout.
Description
Description
20 Amp (16 Amp Max Continuous Load) 125VAC, Medical Grade Surge Protective Power Strip With 6 NEMA 5-20R Outlets With Locking Covers, 15-FT Power Cord.
Specifications
Specifications
Electrical Specifications
| Amperage: | 20 A |
|---|---|
| Cord Length: | 15 Foot |
| Frequency: | 60Hz |
| Grade: | Medical |
| Number of Receptacles: | 6 |
| Surge Protection: | Yes |
| Surge Technology: | MOV |
| Voltage: | 125 VAC |
Environmental Specifications
| Operating Temperature: | 0°C to 40°C |
|---|---|
| Storage Temperature: | -10°C to +50°C |
Material Specifications
| Enclosure: | Powder Coated Steel |
|---|---|
| Line Cord: | #14/3 SJT |
| Outlet Covers: | Polypropylene |
Mechanical Specifications
| HG Outlet Configuration: | NEMA 5-20R |
|---|---|
| HG Plug Configuration: | NEMA 5-20P |
Performance Data
| Inform Technology: | No |
|---|---|
| Joules Rating: | 644J |
| MCOV: | 150V |
| Maximum Leakage Current: | <100µA |
| Maximum Surge Current, Per Mode (L-N): | 27kA |
| Noise Filtering: | -6dB to -29dB (100kHz to 100MHz) |
| Voltage Protection Rating (VPR) L-N, L-G, N-G: | 600V, 600V, 500V |
Standards and Certifications
| ANSI/IEEE: | Category A |
|---|---|
| NFPA: | NFPA 99 2012 ed |
| UL 1363A & CSA C22.2: | No. 21 |
| UL 1449 3rd Ed & CSA C22.2: | No. 8 |
| UL 60601-1 & CSA C22.2: | No.60601-1 |
| UL 60950-1 & CSA C22.2: | No. 60950-1 |
