Brand: Leviton Manufacturing Co
|
SKU:
592982
Leviton 5G110-BP5 | eXtreme Cat 5e QuickPort Jack QuickPack, 25-pack, Purple
Regular price
$173.73
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Leviton 5G110-BP5 | eXtreme Cat 5e QuickPort Jack QuickPack, 25-pac...
Regular price
$173.73
Unit price
Brand: Leviton Manufacturing Co
|
SKU:
592982
Regular price
$173.73
Unit price
Shipping calculated at checkout.
Description
Description
The eXtreme Category 5e Component-Rated UTP Jack is designed to be used with all Leviton QuickPort compatible products. The jack includes patented Retention Force Technology which promotes consistent performance over the life of the system. It includes unique pair separation towers allowing for quicker and easier terminations. The jack is in a 180-degree configuration with the punch field in the back, allowing for rear termination.
Product Features
| Body Color: | Purple |
|---|---|
| Brand: | eXtreme |
| Cable Type: | 8-Conductor UTP Copper Cat 5, 5e and 6 |
| Category Rating: | Cat 5e |
| Color: | Purple |
| Connector Feature: | Channel/Component Rated |
| Contact Base Material: | Phosphor Bronze |
| Contact Sub-Surface Material: | 100 microinches thick Nickel-Plated |
| Contact Surface Material: | 50 microinches thick Gold-Plated |
| Flammability: | Rated V-0 per UL 94 |
| Module Style: | Connector |
| Module Type: | Category 5e |
| Ordering Notes: | Bulk Package of 25 |
| Packaging: | QuickPack 25/bag |
| Position / Conductor: | 8P8C |
| Shielding: | UTP |
| Standards and Certifications: | TIA/EIA cULus Listed |
| Termination Type: | 110 Punchdown |
| Warranty: | 1 Year Limited |
Specifications
Specifications
Material Specifications
| Body Color: | Purple |
|---|---|
| Body Material: | High-Impact Fire-Retardant Plastic |
| Contact Base Material: | Phosphor Bronze |
| Contact Sub-Surface Material: | 100 microinches thick Nickel-Plated |
| Contact Surface Material: | 50 microinches thick Gold-Plated |
Mechanical Specifications
| Cable Type: | 8-Conductor UTP Copper Cat 5, 5e and 6 |
|---|---|
| Connector Feature: | Channel/Component Rated |
| Position / Conductor: | 8P8C |
| Product ID: | Permanently laser-engraved |
| Style Name: | eXtreme |
| Termination Type: | 110 Punchdown |
| Wiring Standard: | T568A T568B |
Performance Specifications
| Module Type: | Category 5e |
|---|
Standards and Certifications
| ACA: | Compliant |
|---|---|
| CSA: | Certified |
| FCC: | Part 68 Compliant |
| ISO/IEC: | 11801 |
| NEC: | Article 800 Compliant |
| TIA/EIA: | TIA-568-B |
| UL: | cULus Listed |
