Leviton ODS15-I1W | Smart Sensor, PIR, Wallbox Occupancy Sensor/Vac...
Description
Description
The Leviton Smart Sensor uses Passive Infrared (PIR) detection technology to monitor a room for occupancy using a segmented, tamper resistent lens. When a person passes in or out of a sensor zone, the sensor detects motion and switches the lights ON. The lights will remain ON as long as an occupant is moving through the sensor zones. The ODS15-Ixx ’s vacancy mode features a Manual-ON/Auto-OFF for installations where manual-ON switching is required for energy code applications. Configuration of ODS15-Ixx is made using the Leviton Smart Sensor App from a smartphone or other Bluetooth® enabled Android or iOS device. Simple configuration can also be applied using pushbutton setup for several popular preconfigured options.
Leviton - ODS15-I1W - Features
- Can be used to comply with IECC, ASHRAE 90.1, and 2019 Title 24, Part 6 occupancy/vacancy sensing and manual control requirements
- Fits in a standard wallbox and gangable with other units
- Controls General Purpose plug loads up to 20A and LED lighting loads up to 10A
- One relay module for single-level switching
- 180° field-of-view provides approximately 1,100 square feet of coverage
- Maximum sensing distance in front of the sensor is 30-40 feet and 15-20 feet on either side
Specifications
Specifications
Leviton - ODS15-I1W - Specifications
| UPC Code: | 78477330135 |
|---|---|
| Frequency : | 60Hz |
| Voltage : | 120 VAC |
| IP Rating : | IP10 |
| Mounting Type : | Wall Switch |
| Switch Type : | Single-Pole |
| Color : | White |
| Sensor Type : | Occupancy / Vacancy |
| Operating Temperature : | 0°C to 40°C |
| Storage Temperature Range : | -40° to 185°F (-40° to 85°C) |
Leviton - ODS15-I1W - Videos
| Leviton ODS15-I1W Video | Click to View |
|---|
Documents and Downloads
Documents and Downloads
