Brand: Leviton Manufacturing Co
|
SKU:
10087635
Leviton OSSMD-MDI | Dual relay multi-tech wall box occupancy sensor w/neutral wire lighting control
Regular price
$151.40
Unit price
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Leviton OSSMD-MDI | Dual relay multi-tech wall box occupancy sensor...
Regular price
$151.40
Unit price
Brand: Leviton Manufacturing Co
|
SKU:
10087635
Regular price
$151.40
Unit price
Description
Description
Dual relay multi-tech wall box occupancy sensor w/neutral wire lighting control, 120/208/220/230/240/277v; 50/60Hz, CEC Title 20/24 Compliant, 30s-30m Time Delay, Ambient Light Override, Self Adjusting, Field Configurable, NAFTA Compliant. Color: Ivory. The OSSMD provides automatic lighting control for two separate loads from a single unit. It is compatible with incandescent, fluorescent, low-voltage lighting, and fan loads. The unit features dual manual-override switches that can be used to toggle the ON/OFF status of each lighting load while an area is occupied. The OSSMD can be installed in place of two single-pole wall switches and fits in a standard single-gang wall box.
Product Features
| Color: | Ivory |
|---|---|
| Coverage (Sq. Ft.): | 2400 |
| Grade: | Commercial |
| Mounting Type: | Wall Switch |
| Product Line: | OSSMD |
| Sensor Type: | Occupancy |
| Technology: | Multi-Technology PIR/Ultrasonic |
Specifications
Specifications
Standards and Certifications
| Color: | Ivory |
|---|---|
| Coverage (Sq. Ft.): | 2400 |
| Grade: | Commercial |
| NAFTA Compliant: | Yes |
| Neutral Wire Connection: | Required |
| Product Line: | OSSMD |
| Switch Type: | Single-Pole, Dual Relay |
| Technology: | Multi-Technology PIR/Ultrasonic |
| Title 24 Compliant: | Yes |
| Voltage: | 120/277 VAC |
Mechanical Specifications
| Neutral Wire Connection: | Required |
|---|---|
| Relay Type: | Dual Relay |
| Switch Type: | Single-Pole, Dual Relay |
Electrical Specifications
| Frequency: | 50/60Hz |
|---|---|
| Voltage: | 120/277 VAC |
Documents and Downloads
Documents and Downloads
- Product Specification and Data Sheet
- Instruction Sheet - French
- Instruction Sheet - Spanish
- Reference - Occupancy Sensor Technology Intro
- Application Note - Changes in Title 24
- Application Note - Energy Policy Act of 2005
- Application Note - IECC VS ASHRAE 90.1-2001
- Application Note - IRS AND ENERGY MANAGEMENT OFFICIAL STATEMENT
- Application Note - How Leviton is Ready to Help You Achieve Leed Points
