Liberty AV DL-SCU-RX | TeamUp+ Series HDBaseT Receiver with USB-Hub...
Description
Description
HDMI Over Twisted Pair Set with power and control Features: HDMI transmission up to 230 feet (70m) 1080p, 4Kx2K & 3D compatible CEC supported Built-in surge protection Diagnostic LEDs HDCP compliant Bidirectional Wideband IR and RS232 passthrough Flexi ble power design (use power supply at TX or RX) Locking Power Connector Applications: Uses any Cat6 or greater twisted pair cabling Extension of HDMI and control signals Limited access to power for extenders on both ends Ideal for Digital Signage, Home Theater, Commercial Video Systems Included items: [1] Transmitter w/ HDMI, 2-way IR, RS232, & flexible power [1] Receiver w/ HDMI, 2-way IR, RS232, & flexible power [1] Power supply w/ locking connector (18vDC 2a) [4] Mounting Brackets with screws [2] 3-pole Euroblock connectors (for RS232) [2] IR Emitters (DIGIB-EMT) [2] IR Receivers (DIGIB-EYE) [1] Installation guide Accessories: 18V DC power supply with locking connector: 18V DC PS
Liberty AV - DL-SCU-RX - Features
- Optional HDBaseT Receiver for SoftCodec switcher / extenders up to 70 meters
- PoH power remotely powers soft codec transmitters from this receiver
- HDMI input adds 1 additional input to the switcher/extender for local sources such as wireless BYOD, AppleTV, or a local computer
- Complete Plug and Play, NO additional driver or software required to be recognized by the computer
- 2 USB-A ports extend the USB hub from the switcher and provide USB2.0 high speed connection back to the transmitter
- Analog audio (Balanced / UnBalanced) audio de-embedding
- 1 RS232 and 2 Relay connections for simple room automation or control. Power on/off display and open/close screen or shades when a signal is presented or removed
- TAA Compliant
Specifications
Specifications
Liberty AV - DL-SCU-RX - Specifications
| UNSPSC Code | 45111800 |
|---|
