Neutrik NAC3FXXB-W-L | Locking Main Connector, 12 mm OD Max, Female...
Description
Description
Locking AC mains cable connector, keyed and color coded (grey) for power-out, screw terminal assembly, for cable diameters 10 to16 mm. The powercon FXXA/FXXB is a single phase (3 conductor) lockable power connector with circuit breaking capability when mated with powercon XX series receptacles. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed to guarantee a safe power connection.
Neutrik - NAC3FXXB-W-L - Features
- IEC EN 60320-1 / UL 60320-1 / CSA C22.2 No. 60320-1 certified, thus accepted as a component for cord sets acc. to IEC 60799 / UL 817 and equipment acc. to IEC 62368-1 , UL US 498 / UL CA 498
- Ergonomic design with slip-proof two-component molded housing
- Power-in (blue) and power-out (grey) versions with di?erent keying to avoid the possibility of intermating
- Unique NEUTRIK locking bushing and strain relief for cable diameters 10 mm to 16 mm
- Easy to assemble because the strain relief locks with the insert mechanically and aligns with the housing
- Superior NEUTRIK quality standard, extremely robust and reliable
- Easy and reliable twist lock system
- Improved kink protection by two-component bushing
Specifications
Specifications
Neutrik - NAC3FXXB-W-L - Product Categories
- Audio, Visual and Telephony
- Audio and Visual
- Audio Equipment
- Other Audio Equipment
Neutrik - NAC3FXXB-W-L - Specifications
| Manufacturer Name | Neutrik |
|---|---|
| Manufacturer Part Number | NAC3FXXB-W-L |
| Item Description | Locking Main Connector, 12 mm OD Max, Female, Single Phase, 6 mm OD Min |
| Cable Outside Diameter Maximum | 12 Mm |
| Cable Outside Diameter Minimum | 6 Mm |
| Color | Blue/Gray |
| Connector Angle | 180 Degree |
| Current Rating | 16 A |
| Enclosure Rating | Ip20 |
| For Use With | Power-Out, Screw Terminal Assembly |
| Material | Copper Alloy, Polyamide, Polyketone, Polypropylene/Tpe, Die-Cast Zinc, Silver-Plated |
| Product Type | Locking Main Connector |
| Special Feature | Single Phase |
| Special Rating | Csa, Iec, Ul |
| Temperature Rating | -33 To 80 C |
| Thread Type | Female |
| Voltage Rating | 250 Vac |
