Brand: Optical Cable Corporation
|
SKU:
373-OCC625-TB06
Optical Cable Corporation BX006DWLS9KR | Fiber Cable, OM1 Fiber, 900µm Tight Buffered Cable, Riser Fire Rating, 2.5mm Subcables
Regular price
$2.04
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Optical Cable Corporation BX006DWLS9KR | Fiber Cable, OM1 Fiber, 90...
Regular price
$2.04
Unit price
Brand: Optical Cable Corporation
|
SKU:
373-OCC625-TB06
Regular price
$2.04
Unit price
Shipping calculated at checkout.
Description
Description
Optical Cable Corporation BX006DWLS9KR | Fiber Cable, OM1 Fiber, 900µm Tight Buffered Cable, Riser Fire Rating, 2.5mm Subcables
Fiber Cable; OM1 Fiber; 9µm Tight Buffered Cable; 6 Fiber; Riser Fire Rating; Armored: Interlocked Armor; 2.5mm Subcables; Black Jacket; PVC Jacket; -4 C Min; 85 C Max; 9.6mm Cable Diameter; Transmission Mode: Multi-Mode
Specifications
Specifications
Optical Cable Corporation - BX006DWLS9KR - Product Categories
- Network Cabling Infrastructure
- Fiber Optic Cabling Infrastructure
- Fiber Optic Cable
- Indoor/Outdoor Fiber Cable
Optical Cable Corporation - BX006DWLS9KR - Specifications
| Manufacturer Name | Optical Cable Corporation |
|---|---|
| Manufacturer Part Number | BX006DWLS9KR |
| Item Description | Fiber Cable, OM1 Fiber, 900µm Tight Buffered Cable, Riser Fire Rating, 2.5mm Subcables |
| Application | Indoor/Outdoor |
| Armor Type | Interlocking |
| Armored | Yes |
| Attenuation | 3.5 dB/km, 1.5 dB/km |
| Bend Radius | 5.7 in. Installation, 3.8 in. Long Term |
| CABLE O.D. (IN.) | 0.38 |
| CABLE TYPE | TIGHT BUFFERED |
| Cable Diameter | 9.6mm |
| Cable Type | 900µm Tight Buffered |
| Construction | Tight Buffer, 900 um |
| Fiber Core Diameter | 62.5/125µm |
| Fiber Count | 6 |
| Fiber Type | OM1 |
| Fire Rating | Riser |
| Jacket Color | Black |
| Jacket Flame Rating | OFNR FT4 |
| Jacket Material | PVC |
| MAX. TENSILE LOAD LONG TERM. N | 1200 |
| MIN. BEND RADIUS INSTALLATION (IN.) | 5.7 |
| MIN. BEND RADIUS LONG TERM (CM) | 9.6 |
| MIN. BEND RADIUS LONG TERM (IN.) | 3.8 |
| Operating Temperature - Maximum | 85 C |
| Operating Temperature - Minimum | -40 C |
| Outside Diameter | 0.38 in. (9.6mm) |
| Product Type | Fiber Optic Cable |
| RODENT PROTECTED | NO |
| Special Feature | 2.5mm Subcables |
| Speed | 62.5um |
| Temperature Rating | -40 to +85 C |
| Transmission Mode | Multi-Mode |
| Type | Indoor Outdoor Direct Burial Cable |
| Wavelength | 850/1310nm |
