Panduit ABM3H-S6-T | ABM3H-S6-T Cable Tie Mount
Description
Description
The cable tie mount in white uses #6 (M3) screws or user supplied adhesive. It is 1.5" long x 1.5" wide (38.1 x 38.1 mm), made of nylon 6.6, which increases mechanical strength, heat and wear resistance, and stiffness. It is used with miniature, intermediate, standard, heavy-standard, light-heavy, heavy, and hook and loop mount cable ties. It is designed for indoor environments and comes in packages of 200.
Cable Tie Mount, No. 6 (M3) Screw, 1.5 Inches x 1.5 Inches (38.1 mm x 38.1 mm), White. Four-way cable tie entry for easy orientation of wires and cables. Mounts can be applied with a screw or with user supplied adhesive. Use with Panduit cable ties for a complete wire routing solution.
Specifications
Specifications
Panduit - ABM3H-S6-T - Product Categories
- Wire Routing, Management & Protection
- Cable Tie Mounts
Panduit - ABM3H-S6-T - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | ABM3H-S6-T |
| Item Description | ABM3H-S6-T Cable Tie Mount |
| Application | Used with Miniature, Intermediate, and Standard Cables Ties |
| Product Type | Cable Tie Mount |
| Color | White |
| Flammability Rating | UL94V-2 |
| Environment | Indoor |
| Material | Nylon 6.6 |
| Maximum Operating Temperature (°C) | 85 |
| Maximum Operating Temperature (°F) | 185 |
| Minimum Operating Temperature (°C) | -60 |
| Minimum Operating Temperature (°F) | -76 |
| Mount Method | Screw |
| Mounting Hole Thread Size | #6 |
| Overall Height (In.) | 0.21 |
| Overall Height (mm) | 5.4 |
| Overall Length (In.) | 1.5 |
| Overall Length (mm) | 38.1 |
| Overall Width (In.) | 1.5 |
| Overall Width (mm) | 38.1 |
| Standards Met | UL Recognized ZODZ2.E136577 and Canadian ZODZ8.E136577; RoHS Compliant |
| For Use With | Miniature, Intermediate, Standard, Light Heavy, Heavy Cross-Section Ties |
Panduit - ABM3H-S6-T - Package Information
| UPC | 07498358474 |
|---|---|
| Standard Package Quantity | 200 |
| Standard Package Volume (cf) | 0.1583 |
| Standard. Ctn. Quantity | 2000 |
| Standard. Ctn. Volume (cf) | 1.5833 |
Panduit - ABM3H-S6-T - Videos
| Video 1 | Click to View |
|---|
