Brand: Panduit
|
SKU:
119728
Panduit ABMS-A-C | ABMS-A-C Cable Tie Mount, Natural, PA 6.6, Rubber Adh., 1.13x1.13", PK100
Regular price
$157.66
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit ABMS-A-C | ABMS-A-C Cable Tie Mount, Natural, PA 6.6, Rubbe...
Regular price
$157.66
Unit price
Description
Description
Panduit ABMS-A-C | ABMS-A-C Cable Tie Mount, Natural, PA 6.6, Rubber Adh., 1.13x1.13", PK100
Panduit’s ABMS-A-C 2-way rubber-based adhesive backed cable tie mounts have been designed for fast installation and long-term performance and reliability. They are made of Nylon 6.6., and can be used with miniature, intermediate, and standard cable ties. Mounts are 1.12" x 1.12" (28.5mm x 28.5mm), white in color and intended for use in indoor environments. They supplied in strips of 2 and come in packages of 500.
Panduit - ABMS-A-C - Features
- 2-Way Cable Tie Entry Mount
- Cable ties may be inersted from either side of mount
- Choose adhesive backed or screw installed mounts
Specifications
Specifications
Panduit - ABMS-A-C - Product Categories
- Wire Routing, Management & Protection
- Cable Tie Mounts
Panduit - ABMS-A-C - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | ABMS-A-C |
| Item Description | ABMS-A-C Cable Tie Mount, Natural, PA 6.6, Rubber Adh., 1.13x1.13", PK100 |
| Application | 2 Way Cable Tie Mount, used With Miniature, Intermediate, and Standard Cable Ties |
| Product Type | Cable Tie Mount |
| Color | Natural |
| Environment | Indoor |
| Material | Nylon 6.6 |
| Maximum Compatible Panel Thickness (In.) | 0.04 |
| Maximum Compatible Panel Thickness (mm) | 1 |
| Maximum Operating Temperature (°C) | 49 |
| Maximum Operating Temperature (°F) | 120 |
| Minimum Operating Temperature (°C) | -29 |
| Minimum Operating Temperature (°F) | -20 |
| Mount Method | Rubber Adhesive Tape |
| Mounting Hole Thread Size | #6 |
| Overall Height (In.) | 0.17 |
| Overall Height (mm) | 4.3 |
| Overall Length (In.) | 1.13 |
| Overall Length (mm) | 28.7 |
| Overall Width (In.) | 1.13 |
| Overall Width (mm) | 50.3 |
| Standards Met | CE Compliant, UL Recognized: E136577, RoHS Compliant |
| Static Load Capacity (kg) | 0.272 |
| Static Load Capacity (lb) | 0.6 |
| For Use With | Miniature, Intermediate Cross-Section Ties |
Panduit - ABMS-A-C - Package Information
| UPC | 07498358002 |
|---|---|
| Standard Package Quantity | 100 |
| Standard Package Volume (cf) | 0.0539 |
| Standard. Ctn. Quantity | 500 |
| Standard. Ctn. Volume (cf) | 0.2695 |
Panduit - ABMS-A-C - Videos
| Video 1 | Click to View |
|---|
