Brand: Panduit
|
SKU:
388503
Panduit ABMT-S6-Q Hook And Loop Cable Tie Mount, Indoor, Includes #6 Screw (M3), Nylon 6.6, 1.12";x1.12"; (28.5mm x 28.5mm), Natural, Pack of 25, Does Not Include Adhesive
Regular price
$87.46
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit ABMT-S6-Q Hook And Loop Cable Tie Mount, Indoor, Includes #...
Regular price
$87.46
Unit price
Description
Description
Panduit ABMT-S6-Q | TAK-TY CABLE TIE MOUNT
The screw applied mount for Tak-Ty hook and loop cable ties in natural uses #6 (M3) screw. It is 1.12" long x 1.12" wide (28.5 x 28.5 mm) and made of nylon 6.6, which increases mechanical strength, heat and wear resistance, and stiffness. It is used with HLT/HLS Tak-Ty hook and loop cable ties, is designed for indoor environments, and comes in packages of 25.
Panduit - ABMT-S6-Q - Features
- Screw applied mount for use with Tak-Ty Hook & Loop Cable Ties.
- Used with Panduit cable ties for a complete wire routing solution
- Adhesive backing allows routing of wires and cables where mounting holes cannot be drilled
- Tear tab provides fast and easy liner removal to speed installation
- For indoor use
Specifications
Specifications
Panduit - ABMT-S6-Q - Product Categories
- Wire Routing, Management & Protection
- Cable Tie Mounts
Panduit - ABMT-S6-Q - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | ABMT-S6-Q |
| Item Description | TAK-TY CABLE TIE MOUNT |
| Application | Use With Hook and Loop Cable Ties |
| Product Type | Cable Tie Mount |
| Color | Natural |
| Flammability Rating | UL94V-2 |
| Environment | Indoor |
| Material | Nylon 6.6 |
| Maximum Compatible Panel Thickness (In.) | 0.04 |
| Maximum Compatible Panel Thickness (mm) | 1 |
| Maximum Operating Temperature (°C) | 85 |
| Maximum Operating Temperature (°F) | 185 |
| Minimum Operating Temperature (°C) | -40 |
| Minimum Operating Temperature (°F) | -40 |
| Mount Method | Screw |
| Mounting Hole Thread Size | #6 |
| Overall Height (In.) | 0.34 |
| Overall Height (mm) | 8.6 |
| Overall Length (In.) | 1.12 |
| Overall Length (mm) | 28.4 |
| Overall Width (In.) | 1.12 |
| Overall Width (mm) | 28.4 |
| Resistance Properties | Heat and Wear Resistant |
| Standards Met | RoHS Compliant |
| Static Load Capacity (kg) | 0.2 |
| Static Load Capacity (lb) | 0.38 |
| Sub Brand | Tak-Ty |
Panduit - ABMT-S6-Q - Package Information
| UPC | 07498385993 |
|---|---|
| Standard Package Quantity | 25 |
| Standard Package Volume (cf) | 0.0185 |
| Standard. Ctn. Quantity | 250 |
| Standard. Ctn. Volume (cf) | 0.1850 |
Panduit - ABMT-S6-Q - Videos
| Video 1 | Click to View |
|---|
