Brand: Panduit
|
SKU:
1009951
Panduit AFR4TRT70IW | Surface Raceway | UPC - 61305644901
Regular price
$25.89
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit AFR4TRT70IW | Surface Raceway | UPC - 61305644901
Regular price
$25.89
Unit price
Description
Description
Panduit Pan-Way Transition Fitting, For Use With: 4-Channel Above Floor Raceway to T70 Surface Raceway, 7.13 in L x 3.49 in W x 3.5 in H, 1 in Bend Radius, ABS, Off-White
Features + Benefits
Panduit AFR4TRT70IW Key Specs
| Raceway Type | Power Rated |
| Fitting Type | T-70 Transition |
| Material | ABS |
| Color | Off-White |
| Overall Length (In.) | 7.13 |
| Overall Length (mm) | 181.1 |
| Overall Width (In.) | 3.49 |
| Overall Width (mm) | 88.6 |
| Overall Height (In.) | 3.5 |
| Overall Height (mm) | 88.9 |
| Internal Area (in²) | 24.88 |
| Internal Area (mm²) | 16045.5 |
| For Use With | T-70 |
| Resistance Properties | Tamper-Resistant |
| Standards Met | UL94V-0 and E116129, UL-5A 600VAC CSA C22.2 No. 62.1-03 600V, RoHS compliant |
| Includes | 1 4-Channel Transition to T70 Base, 1 4-Channel Transition to T70 Cover, 4 HEX Washer Head Concrete Screws |
| Sub Brand | Pan-Way |
| Product Type | Surface Raceway |
| Application | Provides solutions for routing low voltage, fiber optic and/or power cabling over floors. |
Panduit AFR4TRT70IW Data Sheets
| Part Drawings | Above Floor Raceway 4-Channel Transition To T-70 Fitting | Download and View |
| Specification Sheets | Pan-Way Above Floor Raceway System | Download and View |
| Selection Guides | Audio Video Product Selection Guide | Download and View |
| Specification Sheets | Pan-Way Above Floor Raceway System | Download and View |
| Installation Documents | Above Floor Raceway 4-Channel Standard Product | Download and View |
| Installation Documents | Goulotte de câblage à quatre voies au-dessus du plancher - Produit standard | Download and View |
