Panduit BS100645 | One Hole Insulated | UPC - 07498311602
Regular price
$116.32
Unit price
Brand: Panduit
|
SKU:
699144
Regular price
$116.32
Unit price
Description
Description
Panduit StructuredGround Flat Braid Bonding Strap, 1-Hole Non-Insulated, 4 AWG Cable, 6 in Length, 1.06 in Width, 0.13 in Thickness, 3/8 in Mounting Hole, Copper, Tin Plated
Features + Benefits
- Flat ferrule end design helps to reduce the effects of EMI
- Made of high conductivity copper and tin plated to inhibit corrosion
- Seamless ferrule ends provide mechanical strength for improved reliability
- Available with internationally recognized green and yellow insulation for grounding application
Panduit BS100645 Key Specs
| Sub Brand | StructuredGround |
| Product Type | One Hole Insulated |
| Material | Tin-plated Copper, Insulated |
| Color | Green/Yellow |
| Overall Length (In.) | 6 |
| Overall Length (mm) | 152.4 |
| Overall Width (In.) | 1.06 |
| Overall Width (mm) | 27 |
| Ferrule Length (In.) | 1 |
| Ferrule Length (mm) | 25.4 |
| Stud Hole Size (In.) | 0.375 |
| Stud Hole Size (mm) | 10 |
| Application | Control Panel |
| Standards Met | cULus Listed - 467 for Bonding Applications Only |
| Part Features | Flat seamless ferrule end design helps to reduce the effects of EMI (Electromagnetic Interference) |
Panduit BS100645 Data Sheets
| Part Drawings | D-Ring Kit - S1DR | Download and View |
| Installation Documents | Net-Access S-Type Cable Management Panel: CM615C | Download and View |
| Brochures | Net-Access Data Center Cabinet and Net-Containment Systems | Download and View |
