Brand: Panduit
|
SKU:
BSH14-Q
Panduit BSH14-Q Butt Splice, Heat Shrink, 16-14 AWG Range, Yellow, Pack of 5
Regular price
$65.28
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit BSH14-Q Butt Splice, Heat Shrink, 16-14 AWG Range, Yellow, ...
Regular price
$65.28
Unit price
Description
Description
Panduit BSH14-Q | Pan-Term BSH14-Q Butt Splice, Blue, Heat Shrink, 14 AWG, PK25
Panduit BSH14-Q Heat Shrink Insulated Butt Splice
Panduit - BSH14-Q - Features
- Heat Shrink Butt Splice, 16 - 14 AWG wire range.
- Designed to splice two solid or stranded wires together to repair or lengthen wires
- Butted configuration provides low profile for limited space applications
- Heat shrink polyolefin sleeve with hot melt adhesive protects against moisture
- After crimping, heat shrink insulation is completed with a standard heat gun
- Minimum continuous operating temperature -65F (-55C)
- Maximum continuous operation temperature 230F (110C)
- Shrink temperature 250F (120C)
Specifications
Specifications
Panduit - BSH14-Q - Product Categories
- Wire Termination
- Splices
Panduit - BSH14-Q - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | BSH14-Q |
| Item Description | Pan-Term BSH14-Q Butt Splice, Blue, Heat Shrink, 14 AWG, PK25 |
| Product Type | Butt Splice |
| Maximum Copper Conductor Size (AWG STR) | #14 |
| Minimum Copper Conductor Size (AWG STR) | #16 |
| Maximum Metric Conductor Size (mm²) | 2.5 |
| Minimum Metric Conductor Size (mm²) | 1.5 |
| Sub Brand | Pan-Term |
| Copper Conductor Size (AWG) | #16 - #14 |
| Barrel Type | Standard |
| Maximum Voltage (V) | 600 |
| Maximum Voltage (kV) | 0.6 |
| Base Material | Copper |
| Insulation Material | Heat Shrink |
| Insulation Type | Polyolefin |
| Standards Met | BSH14-Q |
| Finish/Coating | Tin-Plated |
| Color Code | Blue |
| Overall Length (In.) | 1.45 |
| Overall Length (mm) | 36.8 |
| Wire Strip Length (In.) | 5/16 |
| Wire Strip Length (mm) | 7.9 |
| UL Temperature Rating (°C) | 125 |
| UL Temperature Rating (°F) | 257 |
| CSA Temperature Rating (°C) | 125 |
| CSA Temperature Rating (°F) | 257 |
| Part Features | • Designed to splice two solid or stranded wires together to repair or lengthen wires • Butted configuration provides low profile for limited space applications • Heat shrink polyolefin sleeve with hot melt adhesive protects against moisture • After crimping, heat shrink insulation is completed with a standard heat gun |
Panduit - BSH14-Q - Package Information
| UPC | 07498381824 |
|---|---|
| Standard Package Quantity | 25 |
| Standard Package Volume (cf) | 0.0067 |
| Standard. Ctn. Quantity | 125 |
| Standard. Ctn. Volume (cf) | 0.0337 |
Panduit - BSH14-Q - Videos
| Video 1 | Click to View |
|---|
