Brand: Panduit
|
SKU:
PAN-BT2S-EA
Panduit BT2S-C | Dome-Top Bt2S-C Barb Tie, Pa6.6, 8"L, 50Lb, Pk100
Regular price
$1.46
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit BT2S-C | Dome-Top Bt2S-C Barb Tie, Pa6.6, 8"L, 50Lb, P...
Regular price
$1.46
Unit price
Description
Description
Panduit BT2S-C | Dome-Top Bt2S-C Barb Tie, Pa6.6, 8"L, 50Lb, Pk100
The BT2S-C Dome-Top barb ty, features a unique patented design with its round smooth edges. Paired with the stainless-steel locking barb, these cable ties provide consistent performance, reliability and infinite adjustability through the entire bundle range. Standard cross section, 8.0" (203mm) length. Appropriate for Indoor use, made of Nylon 6.6, are natural in color and come in packages of 100.
Panduit - BT2S-C - Features
- Panduit Dome-Top Barb-Ty Cable Tie, Plenum Standard, Series: BT Series, 8 in Length, 0.19 in Width, 0.05 in Thickness, 2 in Bundle Dia, Lock Mechanism: Self Locking, 50 lb Tensile, -76 to 185 deg F, Nylon 6.6, Natural
- 2-piece design incorporates a stainless steel locking barb which provides infinite adjustability through entire bundle range
- High loop tensile strength exceeds industry standards and the patented low thread force design reduces operator fatigue and improves productivity
- Dome-Top head having smooth, round edges is easy for installers to handle
- Low threading force reduces operator fatigue and improves productivity
- Ribbed and stippled strap body prevents axial and lateral movement
- Exclusively designed finger grip assures positive grip during threading of tie
- Curved tip is easy to pickup from flat surfaces and allows faster initial threading to speed installation
Specifications
Specifications
Panduit - BT2S-C - Product Categories
- Wire Routing, Management & Protection
- Cable Ties & Wire Ties
Panduit - BT2S-C - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | BT2S-C |
| Item Description | Dome-Top Bt2S-C Barb Tie, Pa6.6, 8"L, 50Lb, Pk100 |
| Product Type | Cable Tie |
| Sub Brand | Dome-Top |
| Color | Natural |
| Environment | Indoor |
| Material | Nylon 6.6 |
| Overall Length (In.) | 8 |
| Overall Length (mm) | 203 |
| Body Width (In.) | 0.185 |
| Body Width (mm) | 4.7 |
| Body Thickness (In.) | 0.045 |
| Body Thickness (mm) | 1.2 |
| Maximum Bundle Diameter (In.) | 2 |
| Maximum Bundle Diameter (mm) | 51 |
| Minimum Bundle Diameter (In.) | 0.06 |
| Minimum Bundle Diameter (mm) | 1.5 |
| Minimum Loop Tensile Strength (N) | 222 |
| Minimum Loop Tensile Strength (lb) | 50 |
| Maximum Operating Temperature (°C) | 85 |
| Maximum Operating Temperature (°F) | 185 |
| Minimum Operating Temperature (°C) | -60 |
| Minimum Operating Temperature (°F) | -76 |
| Minimum Installation Temperature (°C) | -20 |
| Minimum Installation Temperature (°F) | -4 |
| Standards Met | UL 62275 (File E56854), CSA-C22.2 No. 62275, 11130200, NRC 10CFR50, QPL-AS23190, CSA Certified, RoHS Compliant |
| Military Cross Reference Number | MS3367-1-9 |
| For Use With | GTS-E, GS2B-E, GTH-E, GS4H-E, PTS, PTH, PPTS, STS2, STH2 |
| MPN: | BT2S-C |
| Bundle Diameter: | 2 in |
| Color: | Natural |
| Length: | 8 in |
| Lock Mechanism: | Self Locking |
| Material: | Nylon 6.6 |
| Series: | BT Series |
| Temperature Rating: | -76 to 185 deg F |
| Tensile Strength: | 50 lb |
| Thickness: | 0.05 in |
| Type: | Plenum Standard |
| Width: | 0.19 in |
Panduit - BT2S-C - Package Information
| UPC | 07498341176 |
|---|---|
| Standard Package Quantity | 100 |
| Standard Package Volume (cf) | 0.0321 |
| Standard Ctn. Quantity | 1000 |
| Standard Ctn. Volume (cf) | 0.3207 |
Panduit - BT2S-C - Videos
| Video 1 | Click to View |
|---|
