Panduit CD-920-500A | Pan-Lug CD-920 Crimp Dies, 500A, Black Oxide,...
Description
Description
Ensure superior electrical and mechanical connections on large-gauge copper lugs and splices for heavy-duty power applications with our crimp die set.
The CD-920-500A provides circumferential crimp results in terminations with premium electrical and mechanical performance with Panduit copper compression lugs and splices. Crimping dies and connectors are color-coded for easy matching while the part nu mber is permanently marked on the crimping die for easy identification. Crimp die designed for use with Panduit CT-920, CT-920CH, CT-930, CT-930CH, and CT-2920 tools.
Panduit Crimping Die, Series: CD-920, 500 kcmil Cable, Steel
Panduit - CD-920-500A - Features
- Embosses die index number on connector barrels to provide post crimp inspection
- Color coded to provide easy matching to color coding marked on connectors
- Color coded to connector, premium crimp, embosses die number
- Part number permanently marked on crimping die for easy identification
- Provide circumferential crimp results in terminations with premium electrical and mechanical performance
Specifications
Specifications
Panduit - CD-920-500A - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | CD-920-500A |
| Copper Type | Crimp |
| Type | Copper |
| UNSPSC Code | 27112820 |
| Product Type | Crimp Die |
| Sub Brand | Pan-Lug |
| Application | Crimp dies for Panduit Power Connectors and Splices. |
| Color Code | Pink |
| Aluminum Conductor Size (kcmil) | 500 |
| Copper Conductor Size (kcmil) | 500 |
| Flex Conductor Size (kcmil) | 500 |
| Panduit Die Index Number | P99 |
| For Use With | Crimp die for use with Panduit CT-920, CT-2920, CT-930, CT-2930/L, CT-2930/LE, CT-2931 and CT-2931/E crimp tools and CT-930/CH crimp head, can also be used with Panduit CT-2940/L and CT-2940/LE crimp tools and CT-940CH crimp head with CD-940-DA die adapter sold separately. |
| Connection Type | Crimp |
| Crimp Profile | Circumferential |
| Base Material | Steel |
| Finish/Coating | Black Oxide |
| Part Features | Color coded to connector,premium crimp,embosses die number |
| UPC | 07498391454 |
Panduit - CD-920-500A - Environmental Information
| RoHS Status | Not applicable |
|---|---|
| Moisture Sensitivity Level (MSL) | Not Applicable |
| ECCN | EAR99 |
| HTSUS | 8207.30.6095 |
Panduit - CD-920-500A - Videos
| Panduit CD-920-500A Video 1 | Click to View |
|---|---|
| Panduit CD-920-500A Video 2 | Click to View |
