Panduit CMSBUSCZIG | SC Adapter Module
Description
Description
Module supplied with one SC simplex fiber optic adapter with zirconia ceramic split sleeve, International Gray.
SC fiber optic adapters with integrated panel retention clips are TIA/EIA-604 FOCIS-3 compliant. Each SC simplex adapter shall connect one SC connector pair in one Mini-Com space. Each SC duplex adapter shall connect two SC connector pairs in two Mini-Com spaces. SC adapters and adapter Mini-Com shall include phosphor bronze split sleeves for multi-mode applications or zirconia ceramic split sleeves for single mode applications.
Panduit Mini-Com Fiber Optic Adapter Module, SC Simplex Connector, 1 Ports, Single Mode Fiber, For Use With: Mini-Com Modular Patch Panels, Faceplates, Surface Mount Boxes, Plastic, Blue/International Gray
Panduit - CMSBUSCZIG - Features
- Integrated panel retention clips no metal clips to become bent, damaged or lost, simplex adapter clips automatically adjust for FOCIS-10 compliant panel thickness variations for improved mounting
- Short flange design for improved modularity and higher density usage
- Improved protective cap fully surrounds split sleeve opening
- Every adapter is laser marked with QC number to assure 100% traceability
Specifications
Specifications
Panduit - CMSBUSCZIG - Specifications
| Connector Type | Sc |
|---|---|
| Type | Coupler / Adapter |
| UNSPSC Code | 26121600 |
| Sub Brand | Mini-Com |
| Body Style | Simplex |
| Fiber Type | OS1/OS2 |
| Material | Zirconia Ceramic |
| Overall Length (In.) | 1.93 |
| Overall Length (mm) | 49 |
| Standards Met | TIA/EIA-604 FOCIS-3 compliant; exceeds TIA/EIA-568-B.3 requirements. RoHS compliant |
| Product Type | SC Adapter Module |
| Application | Mini-Com Modules, Patch Panels, Faceplates, Surface Mount Boxes |
| Color | Blue |
| Module Color | International Gray |
| Connection Type | SC |
| Part Features | Integrated panel retention clip, Improved adapter protective cap design, Choice of phosphor bronze or zirconia ceramic split sleeves |
| UPC | 07498383241 |
Panduit - CMSBUSCZIG - Environmental Information
| RoHS Status | ROHS3 Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | Not Applicable |
