Panduit CTAP2/0-2/0-X | Structured Ground Comp. Tap, 2/0 - 2/0, Cop...
Description
Description
Safely and reliably connect various wire sizes with our high-performance c-type compression connector, ideal for creating strong electrical connections in your electrical system.
C-type copper compression taps, type CTAP.
Panduit StructuredGround Compression C-Tap Connector, Type CTAP Heavy Duty Standard, C Shape, 1/0 to 2/0 AWG Main/Run, 1/0 to 2/0 AWG Tap, 35 kV, Stranded Copper Conductor, Specifications: 1-1/16 in L Wire Strip, 90 deg C, Copper, 0.8 in L x 0.93 in W x 1.37 in H Dimensions
Panduit - CTAP2/0-2/0-X - Features
- For tapping into unbroken continuous main, as a wire joint or two way splice
- Wide wire range taking capability minimizes inventory requirements
- Made from heavy wall, extruded, high conductivity copper provides high strength and premium electrical properties
- For tapping into unbroken continuous main, as a wire joint or two-way splice
- Wide wire range-taking capability minimizes inventory requirements
- Made from heavy wall, extruded, high conductivity copper; provides high strength and premium electrical properties
- UL Listed per UL 467 for use up to 35 KV and temperature rated 90C when crimped with PANDUIT and specified competitor crimping tools and dies
- UL Listed for grounding and bonding suitable for direct burial in earth or concrete when crimped with PANDUIT and specified competitor crimping tools and dies
Specifications
Specifications
Panduit - CTAP2/0-2/0-X - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | CTAP2/0-2/0-X |
| Component | Compression Taps |
| Connection Type | Compression |
| Material Rating | Copper |
| UNSPSC Code | 39121400 |
| Sub Brand | StructuredGround |
| Maximum Tap Size (AWG STR) | 2/0 |
| Minimum Tap Size (AWG STR) | 1/0 |
| Maximum Run Size (AWG STR) | 2/0 |
| Minimum Run Size (AWG STR) | 1/0 |
| Overall Length (In.) | 0.8 |
| Overall Length (mm) | 20.3 |
| Overall Width (In.) | 0.93 |
| Overall Width (mm) | 23.6 |
| Overall Height (In.) | 1.37 |
| Overall Height (mm) | 34.8 |
| Panduit Die Index Number | PO |
| Burndy Die Index Number | O |
| Wire Strip Length (In.) | 1 1/16 |
| Wire Strip Length (mm) | 27 |
| For Use With | AWG wire only |
| Standards Met | UL 467 listed for Grounding and Bonding and UL 486A for electrical connections up to 35kV. |
| Application | Utility/Ground Grid |
| Product Type | Compression Tap |
| Material | Copper |
| Material Properties | High Conductivity |
| UPC | 07498382131 |
