Panduit CTAPR2/0-2/0-X | Compression Connectors - Taps | UPC - 6130...
Regular price
$19.78
Unit price
Brand: Panduit
|
SKU:
10083340
Regular price
$19.78
Unit price
Description
Description
Panduit Compression Tap, C Shape, #1 AWG Stranded to 2/0 AWG Stranded Main/Run, #1 AWG Stranded to 2/0 AWG Stranded Tap, 90 deg C, Copper, 0.75 in L x 0.74 in W x 1.55 in H Dimensions
Features + Benefits
Panduit Panduit CTAPR2/0-2/0-X | Compression Connectors - Taps | UPC - 61305614291 Key Specs
| Sub Brand | StructuredGround |
| Overall Length (In.) | 0.75 |
| Overall Length (mm) | 19 |
| Material | High Conductivity Copper |
| Overall Width (In.) | 0.74 |
| Overall Width (mm) | 18.8 |
| Overall Height (In.) | 1.55 |
| Overall Height (mm) | 39.37 |
| Maximum Copper Conductor Size (AWG STR) | 2/0 |
| Minimum Copper Conductor Size (AWG STR) | 1 |
| Maximum Ground Rod Size (In.) | 3/8 |
| Maximum Ground Rod Size (mm) | 9.52 |
| Minimum Ground Rod Size (In.) | 3/8 |
| Minimum Ground Rod Size (mm) | 9.52 |
| Panduit Die Index Number | PO |
| Standards Met | cULus Listed for Direct Burial Grounding Applications to UL467 and Power Applications up to 35kV |
| Application | Utility/Ground Grid |
| Product Type | Compression Connectors - Taps |
Panduit Panduit CTAPR2/0-2/0-X | Compression Connectors - Taps | UPC - 61305614291 Data Sheets
| Part Drawings | CTAPR Copper Compression Connectors | Download and View |
| Installation Documents | CTAPR Installation Instruction T-PMPI-327-PC | Download and View |
Panduit Panduit CTAPR2/0-2/0-X | Compression Connectors - Taps | UPC - 61305614291 Environmental Information
| Panduit's RoHS Statement | Download and View |
