Brand: Panduit
|
SKU:
10083316
Panduit CTAPR2/0-2-X | Compression Connectors - Taps | UPC - 61305614290
Regular price
$19.78
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit CTAPR2/0-2-X | Compression Connectors - Taps | UPC - 613056...
Regular price
$19.78
Unit price
Description
Description
Panduit Compression Tap, C Shape, #1 AWG Stranded to 2/0 AWG Stranded Main/Run, #6 AWG Solid to #2 AWG Stranded Tap, 90 deg C, Copper, 0.75 in L x 0.72 in W x 1.43 in H Dimensions
Features + Benefits
- C-Style CU comp conn, #1 AWG str- 2/0 AWG str, 3/8 in rod (M), #6 AWG sol- #2 AWG str (T)
Panduit Panduit CTAPR2/0-2-X | Compression Connectors - Taps | UPC - 61305614290 Key Specs
| Sub Brand | StructuredGround |
| Overall Length (In.) | 0.75 |
| Overall Length (mm) | 19 |
| Material | High Conductivity Copper |
| Overall Width (In.) | 0.72 |
| Overall Width (mm) | 18.3 |
| Overall Height (In.) | 1.43 |
| Overall Height (mm) | 36.3 |
| Maximum Copper Conductor Size (AWG SOL) | 1 |
| Maximum Copper Conductor Size (AWG STR) | 2/0 |
| Minimum Copper Conductor Size (AWG SOL) | 6 |
| Minimum Copper Conductor Size (AWG STR) | 6 |
| Maximum Ground Rod Size (In.) | 3/8 |
| Maximum Ground Rod Size (mm) | 9.52 |
| Minimum Ground Rod Size (In.) | 3/8 |
| Minimum Ground Rod Size (mm) | 9.52 |
| Panduit Die Index Number | PO |
| Standards Met | cULus Listed for Direct Burial Grounding Applications to UL467 and Power Applications up to 35kV |
| Application | Utility/Ground Grid |
| Product Type | Compression Connectors - Taps |
Panduit Panduit CTAPR2/0-2-X | Compression Connectors - Taps | UPC - 61305614290 Data Sheets
| Part Drawings | CTAPR Copper Compression Connectors | Download and View |
| Installation Documents | CTAPR Installation Instruction T-PMPI-327-PC | Download and View |
Panduit Panduit CTAPR2/0-2-X | Compression Connectors - Taps | UPC - 61305614290 Environmental Information
| Panduit's RoHS Statement | Download and View |
