Panduit DNF14-250FIMB-D | Pan-Term Disconnect, Blue, Nylon, 14-16 A...
Description
Description
Our male disconnect offers reliable connections with consistent performance, nylon-insulated design, and tool-free application minimize errors.
The DNF14-250FIMB-D Pan-Term Disconnect is a fully insulated male disconnect with a funnel entry. The internal wire stop assures proper wire insertion length for a higher quality connection. Barrel serrations assure good wire contact and maximum tensil e strength. Oversized insulation housing allows mating with other manufacturer’s female receptacles.
Panduit Pan-Term Male Tab Disconnect, Loose Piece Vibration Resistant, Series: DNF-FIMB, Stranded Conductor, 16 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Butted Seam/Standard Barrel, 600 VAC, 9/32 in L Wire Strip, 0.16 in Dia Maximum Insulation, Standard Barrel Configuration, 221 deg F, Brass, Blue, Nickel Plated, 0.91 in L x 0.45 in W
Panduit - DNF14-250FIMB-D - Features
- Disconnect can be inserted and removed from the male tab without the use of tools for lower installed cost
- Fully insulated design provides protection from electrical shorts
- Internal barrel serrations assure good wire contact and maximum tensile strength
- Internal wire stop assures proper length of insertion into terminal barrel, providing a higher quality connection
- Coupler, male and female parts sold separately
- Maximum insulation temperature 221 deg F
- UL flammability UL 94V-2/HB, maximum insulation temperature 221 deg F (105 deg C)
- UL and CSA rated up to 600 VAC per UL 310
- Nylon barrel insulated
- Disconnect can be inserted and removed from the male tab without the use of tools for lower installed cost
- Fully insulated design provides protection from electrical shorts
- Internal barrel serrations assure good wire contact and maximum tensile strength
- Internal wire stop assures proper length of insertion into terminal barrel, providing a higher quality connection
- UL Flammability UL 94V-2/HB, maximum insulation temperature 221F (105C)
- Coupler, male, and female parts sold separately
Specifications
Specifications
Panduit - DNF14-250FIMB-D - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | DNF14-250FIMB-D |
| Type | Copper - Other |
| UNSPSC Code | 39121400 |
| Disconnect Type | Male Tab Disconnect |
| Insulation Material | Nylon |
| Insulation Type | Fully Insulated |
| Maximum Copper Conductor Size (AWG) | #14 |
| Maximum Wire Size (AWG) | 14 |
| Minimum Wire Size (AWG) | #16 |
| Wire Strip Length (In.) | 9/32 |
| Wire Strip Length (mm) | 7.1 |
| Tab Size (In.) | 0.250 x 0.032 |
| Tab Size (mm) | 6.3 x 0.8 |
| Standards Met | UL 310, CSA 22.2 No.153 |
| Maximum Voltage (V) | 600 |
| Base Material | Brass |
| Finish/Coating | Nickel-Plated |
| Color Code | Blue |
| Barrel Type | Standard |
| Flammability Rating | UL94-HB |
| Maximum Operating Temperature (°C) | 105 |
| Maximum Operating Temperature (°F) | 221 |
| Sub Brand | Pan-Term |
| Maximum Metric Conductor Size (mm²) | 2.5 |
| UPC | 07498382417 |
Panduit - DNF14-250FIMB-D - Videos
| Panduit DNF14-250FIMB-D Video 1 | Click to View |
|---|---|
| Panduit DNF14-250FIMB-D Video 2 | Click to View |
