Panduit DNF18250FIMX-2K | Disconnects on a Reel | UPC - 07498334343
Regular price
$1,327.35
Unit price
Brand: Panduit
|
SKU:
PAN-DNF18-250FIMX-2K
Regular price
$1,327.35
Unit price
Shipping calculated at checkout.
Description
Description
Panduit Reel Smart Male Tab Disconnect, Vibration Resistant, Series: DNF-FIMX, Stranded Conductor, 22 to 18 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Butted Seam/Expanded Barrel, 600 VAC, 9/32 in L Wire Strip, 0.244 in Dia Insulation, HB Flammability Rating, 221 deg F, Brass, Red, Nickel Plated, 0.97 in L x 0.41 in W
Features + Benefits
- Disconnect can be inserted and removed from the male tab without the use of tools for lower installed cost
- Fully insulated design provides protection from electrical shorts
- Internal barrel serrations assure good wire contact and maximum tensile strength
- Internal wire stop assures proper length of insertion into terminal barrel, providing a higher quality connection
- Nylon barrel insulated
Panduit DNF18250FIMX-2K | Disconnects on a Reel | UPC - 07498334343 Key Specs
| Disconnect Type | Male Tab Disconnect |
| Insulation Material | Nylon - Barrel Insulated |
| Maximum Copper Conductor Size (AWG) | #22 |
| Maximum Wire Size (AWG) | #22 |
| Minimum Wire Size (AWG) | #18 |
| Minimum Copper Conductor Size (AWG) | #18 |
| Wire Strip Length (In.) | 0.28 |
| Wire Strip Length (mm) | 7.1 |
| Tab Size (In.) | 0.25 |
| Tab Size (mm) | 6.3 |
| Standards Met | UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153 |
| Maximum Voltage (V) | 600 |
| Base Material | Brass |
| Finish/Coating | Nickel |
| Color Code | Red |
| Flammability Rating | HB |
| Insulation Diameter (In.) | 0.24 |
| Insulation Diameter (mm) | 6.2 |
| Maximum Operating Temperature (°C) | 105 |
| Maximum Operating Temperature (°F) | 221 |
Panduit DNF18250FIMX-2K | Disconnects on a Reel | UPC - 07498334343 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - DNF18-250FIM-2K Product Page | Download and View |
| Part Drawings | Disconnect male fully insul expanded entry | Download and View |
| Selection Guides | Terminal Tools Selection Guide | Download and View |
Panduit DNF18250FIMX-2K | Disconnects on a Reel | UPC - 07498334343 Environmental Information
| Panduit's RoHS Statement | Download and View |
