Brand: Panduit
|
SKU:
10044122
Panduit DNH10-250FI-E | Loose Piece Disconnect | UPC - 07498381831
Regular price
$258.14
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit DNH10-250FI-E | Loose Piece Disconnect | UPC - 07498381831
Regular price
$258.14
Unit price
Description
Description
Panduit Pan-Term Female Disconnect, Heat Shrink Loose Piece, Series: DNH-FI, Stranded Conductor, 12 to 10 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Sleeve/Standard Barrel, Crimp Terminal, 600 VAC, 9/32 in L Wire Strip, 0.23 in Dia Maximum Insulation, 230 deg F, Brass, Yellow, Tin Plated, 1.44 in L x 0.35 in W x 0.27 in H, Fully Insulated
- Disconnect can be inserted and removed from the male tab without the use of tools for lower installed cost
- Premium nylon insulation retains its shape when crimped and provides a tight grip around the wire insulation for maximum strain relief
- Fully insulated design provides protection from electrical shorts
- Internal wire stop assures proper length of insertion into terminal barrel, providing a higher quality connection
Panduit Panduit DNH10-250FI-E | Loose Piece Disconnect | UPC - 07498381831 Key Specs
| Disconnect Type | Female Disconnect |
| Insulation Material | Heat Shrink - Fully Insulated |
| Maximum Copper Conductor Size (AWG) | #10 |
| Maximum Wire Size (AWG) | #10 |
| Minimum Wire Size (AWG) | #12 |
| Minimum Copper Conductor Size (AWG) | #12 |
| Wire Strip Length (In.) | 0.28 |
| Wire Strip Length (mm) | 7.1 |
| Tab Size (In.) | 0.25 |
| Tab Size (mm) | 6.3 |
| Standards Met | UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153 |
| Maximum Voltage (V) | 600 |
| Base Material | Brass |
| Finish/Coating | Tinned |
| Color Code | Yellow |
| Barrel Type | Sleeved Barrel |
| Flammability Rating | HB |
| Insulation Diameter (In.) | 0.23 |
| Insulation Diameter (mm) | 5.8 |
| Maximum Operating Temperature (°C) | 110 |
Panduit Panduit DNH10-250FI-E | Loose Piece Disconnect | UPC - 07498381831 Environmental Information
| Panduit's RoHS Statement | Download and View |
