Brand: Panduit
|
SKU:
DPF14-250FIM-2K
Panduit DPF14-250FIM-2K | Disconnects on a Reel | UPC - 07498320328
Regular price
$2.76
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit DPF14-250FIM-2K | Disconnects on a Reel | UPC - 07498320328
Regular price
$2.76
Unit price
Brand: Panduit
|
SKU:
DPF14-250FIM-2K
Regular price
$2.76
Unit price
Shipping calculated at checkout.
Description
Description
Panduit Reel Smart Male Disconnect, Vibration Resistant, Series: DPF-FIM, Stranded Conductor, 16 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Butted Seam/Funnel Entry Barrel, 600 VAC, 9/32 in L Wire Strip, 0.156 in Dia Insulation, V2 Flammability Rating, 221 deg F, Brass, Blue, Nickel Plated, 0.9 in L x 0.41 in W
Features + Benefits
- Nylon barrel insulated
Panduit DPF14-250FIM-2K | Disconnects on a Reel | UPC - 07498320328 Key Specs
| Disconnect Type | Male Tab Disconnect |
| Insulation Material | Premium Nylon - Fully Insulated |
| Maximum Copper Conductor Size (AWG) | #14 |
| Maximum Wire Size (AWG) | #14 |
| Minimum Wire Size (AWG) | #16 |
| Minimum Copper Conductor Size (AWG) | #16 |
| Wire Strip Length (In.) | 0.28 |
| Wire Strip Length (mm) | 7.1 |
| Tab Size (In.) | 0.25 |
| Tab Size (mm) | 6.3 |
| Standards Met | UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153 |
| Maximum Voltage (V) | 600 |
| Base Material | Brass |
| Finish/Coating | Nickel |
| Color Code | Blue |
| Flammability Rating | V2 |
| Insulation Diameter (In.) | 0.16 |
| Insulation Diameter (mm) | 4.1 |
| Maximum Operating Temperature (°C) | 105 |
| Maximum Operating Temperature (°F) | 221 |
Panduit DPF14-250FIM-2K | Disconnects on a Reel | UPC - 07498320328 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - DPF18-250FIM-2K Product Page | Download and View |
| Part Drawings | Part Drawing - PDF - A4151405 | Download and View |
| Selection Guides | Terminal Tools Selection Guide | Download and View |
Panduit DPF14-250FIM-2K | Disconnects on a Reel | UPC - 07498320328 Environmental Information
| Panduit's RoHS Statement | Download and View |
