Panduit F92ERQ1Q1SNM009 | LC Patch Cord | UPC - 07498307687
Description
Description
Push-pull LC duplex fiber optic patch cords containing the custom push-pull strain relief boot and duplex clip, allow users easy accessibility when deploying very high density LC patch fields in data center applications. Available in riser (OFNR) and low smoke zero halogen (LSZH) rated jacket materials to comply with local cabling ordinances and OM4, OM3 or OS1/OS2 fiber types to meet the demands of today's highest speed applications.
Panduit Opti-Core Fiber Optic Patch Cord, 2 Fibers, 29.53 ft Length, LC Duplex to LC Duplex Connector, 9 um Core Dimension, 125 um Clad Dimension, OS1/OS2, Yellow
Features + Benefits
- Minimize waste, optimize cable management, speed deployment, improve flexibility and manageability for lower installation cost
Panduit F92ERQ1Q1SNM009 Key Specs
| Fiber Type | OS1/OS2 |
| Number of Fibers | 2 |
| Connector 1 Type | LC Duplex |
| Connector 2 Type | LC Duplex |
| Flammability Rating | Riser |
| Maximum Connector Insertion Loss (dB) | 0.35 |
| Minimum Connector Return Loss (dB) | 55 |
| Overall Length (ft.) | 29.5 |
| Overall Length (m) | 9 |
| Fiber Diameter (µm) | 9 |
| Outer Diameter (In.) | 0.06 |
| Outer Diameter (mm) | 1.6 |
| Maximum Operating Temperature (°C) | 60 |
| Maximum Operating Temperature (°F) | 140 |
| Minimum Operating Temperature (°C) | -10 |
| Minimum Operating Temperature (°F) | 14 |
| Maximum Installation Temperature (°C) | 60 |
| Maximum Installation Temperature (°F) | 140 |
| Minimum Installation Temperature (°C) | -10 |
| Minimum Installation Temperature (°F) | 14 |
Panduit F92ERQ1Q1SNM009 Data Sheets
| Part Drawings | StrongHold Standard Ties 00092FBK_DC | Download and View |
| Flyers | StrongHold General Purpose Contractor Ties | Download and View |
| Application Guides | Best Seller Products for Industrial Construction, MRO and OEM Application Guide ELCB33 | Download and View |
