Panduit F9E10D-10DM1 | Keyed LC Patch Cord | UPC - 07498307596
Regular price
$104.79
Unit price
Brand: Panduit
|
SKU:
687404
Regular price
$104.79
Unit price
Description
Description
LC (keyed D yellow) to LC (keyed D yellow) singlemode duplex patch cord, 16mm jacketed cable (one duplex keyed LC connector on each end) 9/125µm
Panduit F9E10D-10DM1 Key Specs
| Note | Intended for use in fixed installations which are outside the scope of RoHS |
| Fiber Type | OS1/OS2 |
| Number of Fibers | 2 |
| Connector 1 Type | Keyed LC |
| Connector 2 Type | Keyed LC Duplex |
| Flammability Rating | Riser |
| Maximum Connector Insertion Loss (dB) | 0.35 |
| Minimum Connector Return Loss (dB) | 55 |
| Overall Length (ft.) | 3.28 |
| Overall Length (m) | 1 |
| Fiber Diameter (µm) | 9 |
| Resistance Properties | Flame-Resistant |
| Cable Color | Yellow |
| Standards Met | RoHS directive is not applicant. Compliant with TIA/EIA-568-B.3, IEC-61754-7 (International), and UL1666 (OFNR) or NFPA 262 (OFNP) flame ratings |
| Application | Primary application is FTTD deployments that require a level of visual and mechanical differentiation, and physical layer security that conventional connector solutions cannot provide. |
| Body Style | Duplex |
| Product Type | Keyed LC Patch Cord |
| Sub Brand | Opti-Core |
Panduit F9E10D-10DM1 Data Sheets
| Specification Sheets | Specification Sheet - WW-FBSP31 (Keyed LC OFNR OFNP PC Pgls Final 6910 | Download and View |
| Catalog Cut Sheets | Catalog Cut Sheet - F9E10A-10AM1 Product Page | Download and View |
