Panduit FAP8WSPEDLCZ | Keyed LC Fiber Adapter Panel
Description
Description
Keyed LC FAP loaded with eight LC (keyed S ’" peach) duplex fiber optic adapters with zirconia ceramic split sleeves.
Fiber adapter panels contain TIA/EIA-604 FOCIS compliant or compatible simplex or duplex fiber optic adapters and meet or exceed TIA/EIA-568-C.3 requirements. Fiber adapter panels include horizontal and vertical MPO adapters, LC, keyed LC, SC, ST, FC, MT-RJ or E-2000 fiber optic adapters. Fiber optic adapters include phosphor bronze or zirconia ceramic split sleeves to fit specific network requirements. LC and SC adapter housing colors follow the TIA/EIA-568-C.3 suggested color identification scheme. Multimedia modular panels allow customization of installation for applications requiring integration of fiber optic and copper cables. Blank fiber adapter panels reserve fiber adapter panel space for future use.
Panduit Opticom Fiber Optic Adapter Panel, Duplex Loaded, Keyed LC End A, 8 Fibers, OM1/OM2/OM3/OM4/OS1/OS2 Fiber, Rack/Wall Mounting, Zirconia Ceramic, Black
Panduit - FAP8WSPEDLCZ - Features
- 100% performance tested
- Robust construction
- Provides identification of performance level, length and quality control number for future traceability
- Patented tangle free latch on modular plugs
- Meets individual length requirements for greater system flexibility
- Jack module black plug
- Snaps quickly into Opticom fiber adapter patch panels and enclosures
- Assures flexibility and ease of network deployment and moves adds and changes
- Easy identification of fiber type via adapter colors
- Visually compatible with patch cords and connectivity that also follows the color identification scheme
Specifications
Specifications
Panduit - FAP8WSPEDLCZ - Specifications
| Connector Type | Lc |
|---|---|
| Enclosure Type | Opticom |
| UNSPSC Code | 43223328 |
| Connection Type | Keyed LC |
| Fiber Type | OM3/OM4, OM2, OM1 and OS1/OS2 |
| Material | Zirconia Ceramic |
| Adapter Color | Peach |
| Overall Width (In.) | 4.3 |
| Overall Width (mm) | 109 |
| Overall Depth (mm) | 27 |
| Overall Depth (In.) | 1.08 |
| Overall Height (In.) | 1.38 |
| Overall Height (mm) | 35 |
| Number of Ports | 8 |
| Standards Met | RoHS compliant. Meets or exceeds TIA/EIA-568-C.3 requirements |
| Product Type | Keyed LC Fiber Adapter Panel |
| Application | Used with Opticom Rack and Wall Mount Enclosures, Fiber Adapter Patch Panels, and Opticom Zero RU Fiber Adapter Panel Brackets to deploy medium to high-density fiber optic network applications as specified in the data center cabling standard TIA 942 for cross connects in main distribution, horizontal distribution, and equipment distribution areas |
| Color | Black |
| Sub Brand | Opticom |
| UPC | 07498327461 |
Panduit - FAP8WSPEDLCZ - Environmental Information
| RoHS Status | ROHS3 Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | Not Applicable |
