Panduit FAPH1624RDMPO | Opticom FAP, 16 Key-Up/Key-Down MPOs, Type A, Red, Horizontal
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit FAPH1624RDMPO | Opticom FAP, 16 Key-Up/Key-Down MPOs, Type ...
Description
Description
Our MPO fiber optic adapter panel offers versatile connectivity for your data centers, providing easy installation, customizable configurations, and reliable fiber optic connections.
Opticom 100G MPO fiber adapter panel (FAP) loaded with sixteen (16) Type A key-up/key-down red MPO fiber optic adapters, horizontal orientation.
Fiber adapter panels contain TIA/EIA-604 FOCIS compliant or compatible simplex or duplex fiber optic adapters and meet or exceed TIA/EIA-568-C.3 requirements. Fiber adapter panels include horizontal and vertical MPO adapters, LC, keyed LC, SC, ST, FC, MT-RJ or E-2000 fiber optic adapters. Fiber optic adapters include phosphor bronze or zirconia ceramic split sleeves to fit specific network requirements. LC and SC adapter housing colors follow the TIA/EIA-568-C.3 suggested color identification scheme. Multimedia modular panels allow customization of installation for applications requiring integration of fiber optic and copper cables. Blank fiber adapter panels reserve fiber adapter panel space for future use. All fiber adapter panels snap quickly into the front of fiber optic patch panels and enclosures for easy network deployment or moves, adds, and changes.
Panduit Opticom Fiber Optic Adapter Panel, Loaded, MPO End A, 24 Fibers, OM1/OM2/OM3/OM4/OS1/OS2 Fiber, Surface Mounting, Red
Panduit - FAPH1624RDMPO - Features
- Snap quickly into the front of all Opticom and Opticom QuickNet components
- Assures flexibility and ease of network deployment and moves, adds and changes
- Easy identification of fiber type via adapter colors
- Visually compatible with patch cords and connectivity that also follows the color identification scheme
Specifications
Specifications
Panduit - FAPH1624RDMPO - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | FAPH1624RDMPO |
| Connector Type | Mpo |
| Enclosure Type | Opticom |
| UNSPSC Code | 43223328 |
| Connection Type | LC |
| Fiber Type | OM1/OM2/OM3/OM4/OS2 |
| Material | Plastic |
| Adapter Color | Red |
| Fiber Polarity | Method A |
| Overall Depth (In.) | 0.8 |
| Overall Depth (mm) | 21 |
| Overall Width (In.) | 4.3 |
| Overall Width (mm) | 109.1 |
| Overall Height (In.) | 1.38 |
| Overall Height (mm) | 35.2 |
| Number of Ports | 16 |
| Standards Met | EIA-310/IEC 60297, RoHS compliant |
| Product Type | Front Loading Adapter Panel |
| Color | Black |
| Sub Brand | Opticom |
| UPC | 07498376463 |
Panduit - FAPH1624RDMPO - Environmental Information
| RoHS Status | ROHS3 Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | Not Applicable |
