Panduit FC29N-12-03AF | OptiCom MPO-SC Fiber Cassette OS2, 12 Fiber...
Description
Description
Streamline your high-density data center connections with our pre-terminated MTP fiber optic cassette. Flexible offering of LC, SC, or simplex adapter options, all within a space-saving design.
OS1/OS2 12-fiber total, standard loss, SC duplex adapter cassette (color and split sleeve dictated by fiber type), Modified Method A (flipped-pairs)
Panduit Opticom QuickNet Fiber Optic Cassette, Modified Method A Pair Flipped Standard, Duplex Adapter, SC Duplex End A, MPO Male End B, 12 Fibers, 9/125 um OS2 Singlemode Fiber, Zirconia Ceramic Connector
Specifications
Specifications
Panduit - FC29N-12-03AF - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | FC29N-12-03AF |
| Connector Type | Sc Duplex |
| Fiber Count | 12 |
| UNSPSC Code | 43223328 |
| Fiber Type | OS2 |
| Sub Brand | Opticom |
| Number of Fibers | 12 |
| Connector 1 Type | SC Duplex |
| Connector 2 Type | MPO-12 Male |
| Adapter Color | Blue |
| Maximum Connector Insertion Loss (dB) | 0.75 |
| Minimum Connector Return Loss (dB) | 26 |
| Product Type | Fiber Cassette |
| Part Features | Quick and easy deployment in high density applications and provide efficient utilization of rack space and design flexibility. |
| UPC | 07498395170 |
Panduit - FC29N-12-03AF - Environmental Information
| RoHS Status | ROHS3 Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | Not Applicable |
Documents and Downloads
Documents and Downloads
- Panduit FC29N-12-03AF Specification Sheet
- Panduit FC29N-12-03AF Technical References
- Panduit FC29N-12-03AF Installation Documents
- Panduit FC29N-12-03AF Application Guides
- Panduit FC29N-12-03AF Part Drawings
- Panduit FC29N-12-03AF Specification Sheets
- Panduit FC29N-12-03AF Application Guides
- Panduit FC29N-12-03AF RoHS Statement
