Brand: Panduit
|
SKU:
681187
Panduit FC2XO-06-03AF | QuickNet™ MTP Fiber Optic Cassette
Regular price
$439.15
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit FC2XO-06-03AF | QuickNet™ MTP Fiber Optic Cassette
Regular price
$439.15
Unit price
Description
Description
Panduit FC2XO-06-03AF | QuickNet™ MTP Fiber Optic Cassette
OM3 6-fiber, optimized, low loss, SC duplex adapter cassette, (color and split sleeve dictated by fiber type), modified method A (flipped-pairs)
Streamline your high-density data center connections with our pre-terminated MTP fiber optic cassette. Flexible offering of LC, SC, or simplex adapter options, all within a space-saving design.
Panduit - FC2XO-06-03AF - Features
- Minimize waste
- Optimize cable management
- Speed deployment, improve flexibility and manageability
Specifications
Specifications
Panduit - FC2XO-06-03AF - Specifications
| Connector Type | Sc Duplex |
|---|---|
| Fiber Count | 6 |
| UNSPSC Code | 43223328 |
| Fiber Type | OM3 |
| Sub Brand | Opticom® |
| Number of Fibers | 6 |
| Connector 1 Type | SC Duplex |
| Connector 2 Type | MPO-12 Male |
| Adapter Color | Aqua |
| Material | Zirconia Ceramic |
| Maximum Connector Insertion Loss (dB) | 0.5 |
| Minimum Connector Return Loss (dB) | 26 |
| Overall Width (In.) | 3.5 |
| Overall Width (mm) | 89 |
| Overall Height (In.) | 1.4 |
| Overall Height (mm) | 35 |
| Overall Depth (In.) | 4.2 |
| Overall Depth (mm) | 106 |
| Product Type | SC Cassette |
| Application | Cable Management |
| Standards Met | Meets or exceeds TIA/EIA-568-C.3 performance requirements. Supports IEEE 802.3ae and ANSI T11.2 (Fiber Channel) channel and link specifications. Compliant with ROHS 2002/95/EC. |
| Color | Aqua |
| Fiber Diameter (µm) | 50 |
| Part Features | Quick and easy deployment in high density applications and provide efficient utilization of rack space and design flexibility. |
| UPC | 07498395188 |
Panduit - FC2XO-06-03AF - Package Information
| UPC | 07498395188 |
|---|---|
| Standard Packaging Quantity | 1 |
| Standard Packaging Volume (cf) | 0.0984 |
| Standard Ctn. Quantity | 10 |
| Standard Ctn. Volume (cf) | 0.9835 |
Documents and Downloads
Documents and Downloads
- Panduit FC2XO-06-03AF Specification Sheet
- Panduit FC2XO-06-03AF Part Drawings
- Panduit FC2XO-06-03AF Technical References
- Panduit FC2XO-06-03AF Installation Documents
- Panduit FC2XO-06-03AF Application Guides
- Panduit FC2XO-06-03AF Specification Sheets
- Panduit FC2XO-06-03AF Application Guides
- Panduit FC2XO-06-03AF RoHS Statement
