Panduit FC2ZN-24-10AF | OptiCom MPO-LC Fiber Cassette OM4, 24 Fiber...
Description
Description
Streamline your high-density data center connections with our pre-terminated MTP fiber optic cassette. Flexible offering of LC, SC, or simplex adapter options, all within a space-saving design.
The OptiCom Fiber Cassette is OM4, and features 2 MPO to 12 duplex LC and supports 24 fibers total. It is standard IL and uses Modified Method A polarity with flipped pairs. The cassette has a black cover with 2 black MPO connectors and 12 aqua LC adap ters.
Panduit Opticom QuickNet Fiber Optic Cassette, Modified Method A Pair Flipped Standard, Duplex Adapter, LC Duplex End A, Male MPO End B, 24 Fibers, 10Gig 50/125 um OM4 Multi-Mode Fiber, Zirconia Ceramic Connector
Specifications
Specifications
Panduit - FC2ZN-24-10AF - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | FC2ZN-24-10AF |
| Connector Type | Lc |
| Fiber Count | 24 |
| UNSPSC Code | 43223328 |
| Fiber Type | OM4 |
| Sub Brand | Opticom |
| Number of Fibers | 24 |
| Connector 1 Type | LC Duplex |
| Connector 2 Type | MPO-12 Male |
| Adapter Color | Aqua |
| Maximum Connector Insertion Loss (dB) | 0.75 |
| Minimum Connector Return Loss (dB) | 26 |
| Product Type | Fiber Cassette |
| Part Features | Quick and easy deployment in high density applications and provide efficient utilization of rack space and design flexibility. |
| UPC | 07498395126 |
Panduit - FC2ZN-24-10AF - Environmental Information
| RoHS Status | ROHS3 Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | Not Applicable |
Documents and Downloads
Documents and Downloads
- Panduit FC2ZN-24-10AF Specification Sheet
- Panduit FC2ZN-24-10AF Part Drawings
- Panduit FC2ZN-24-10AF Technical References
- Panduit FC2ZN-24-10AF Installation Documents
- Panduit FC2ZN-24-10AF Application Guides
- Panduit FC2ZN-24-10AF Specification Sheets
- Panduit FC2ZN-24-10AF Application Guides
- Panduit FC2ZN-24-10AF RoHS Statement
