Panduit FOKPZ12 | Indoor/Outdoor Tight Buffered Cable | UPC - 07498...
Description
Description
Panduit Opti-Core Indoor/Outdoor All-Dielectric Cable with tight buffered fibers are an integral part of the Panduit end-to-end fiber optic solution, designed to support today's data needs while meeting tomorrow's ever-advancing network requirements. This cable provides water blocking technology, high density and easy installation in transitional aerial and duct applications and entrance facilities and the 900 um tight-buffered fibers provides easy connectorization.
Panduit Opti-Core Dielectric Cable, Multi-Mode (OM4), 12 Fibers, PVC, Black, -40 to 176 deg F
Features + Benefits
- The tight buffered fibers surrounded by aramid yarn strength members combine usability indoors and out
- Cables with greater than 24 fibers feature a sub-unit design that simplifies fiber identification, provides easy access and routing of the fibers
- It also increases cable durability with a dielectric central strength member
- Opti-Core fiber optic indoor/outdoor riser (OFNR) and plenum (OFNP) rated all-dielectric cable with tight buffered fibers are tested in accordance with Telcordia GR-20, Issue 2, GR-409 and with relevant EIA/TIA-455 series FOTPs for fiber optic cable
- All multimode and singlemode cable is available in 2, 4, 6, 8, 12, and 24-fiber counts as a non-subunitized design and in 36, 48, 72, and 96-fiber counts (144 for Riser) as a sub-unitized design
- 150 lb tensile strength
- OM4 10G 50/125um fiber size
- Plenum flame rating
- 0.24 in OD Cable
Panduit FOKPZ12 Key Specs
| Cable Construction | Tight Buffered Unarmored |
| Sub Brand | Opti-Core |
| Environment | Indoor/Outdoor |
| Fiber Type | OM4 |
| Number of Fibers | 12 |
| Fiber Diameter (µm) | 50 |
| Minimum Operating Temperature (°C) | -40 |
| Minimum Operating Temperature (°F) | -40 |
| Minimum Installation Temperature (°F) | 32 |
| Cable Color | Black |
| Flammability Rating | Plenum |
| Product Type | Indoor/Outdoor Tight Buffered Cable |
| Part Features | This cable provides water blocking technology, high density, and easy installation in transitional aerial and duct applications and entrance facilities. |
Panduit FOKPZ12 Data Sheets
| Installation Documents | Net-Access Cable Management Panel | Download and View |
| Part Drawings | 700mm-800mm x 42-51RU Expandable Cable Management Panel (SN*VCM*) | Download and View |
