Brand: Panduit
|
SKU:
265264
Panduit FR4X4BL6 | FIBERRUNNER CHANNEL, 4X4 SYSTEM, 6 FT LENGTH, BLACK
Regular price
$183.08
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit FR4X4BL6 | FIBERRUNNER CHANNEL, 4X4 SYSTEM, 6 FT LENGTH, BLACK
Regular price
$183.08
Unit price
Description
Description
Panduit FR4X4BL6 | FIBERRUNNER CHANNEL, 4X4 SYSTEM, 6 FT LENGTH, BLACK
The FiberRunner 4x4 Channel can be used with fittings and brackets to design a routing system to separate, route, and protect fiber optic and high-performance copper cables. The cable routing channel accepts cable retainers or a hinged cover.
Panduit - FR4X4BL6 - Features
- Used to carry the cables horizontally throughout the system. Accepts hinged cable retainers FRCR4BL-X, hinged cover FRHC4BL6 or split hinged cover FRSHC4BL6. Use QuikLock(TM) couplers FRBC4X4BL to attach channel and/or fittings.
- Robust 4x4 system ideal for use with smaller cable counts
- Multiple spillout options provide versatility to mate to various equipment and rack configurations
- QuikLock(TM) couplers and brackets reduce system installation time dramatically
- Channel, covers, fittings and other non-metallic system components made from V-0 flame class rated material
- Compatible with all sizes of Panduit(TM) FiberRunner(TM) and Panduit(TM) Fiber-Duct(TM) Routing Systems, cable management, and racks
- Compliant with the applicable tests in Telcordia GR-63-CORE Network Equipment Building Systems (NEBS) Level 3
- For other standard colors replace suffix YL (Yellow) with OR (Orange) or BL (Black)
Specifications
Specifications
Panduit - FR4X4BL6 - Product Categories
- Wire Routing, Management & Protection
- Fiber Routing Channel & Covers
Panduit - FR4X4BL6 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | FR4X4BL6 |
| Item Description | FIBERRUNNER CHANNEL, 4X4 SYSTEM, 6 FT LENGTH, BLACK |
| Application | (1)The Fiber-Runner 4X4 Routing Systems are Comprised of Channel, Fittings, and Brackets Designed to Segregate, Route, and Protect Fiber Optic Cable and Copper Cabling.(2) It is Suited for Data Center Applications where Cable is Routed from Distribution |
| Product Type | Channel |
| Channel Material | Rigid PVC |
| Color | Black |
| For Use With | FRCR4BL-X,FRHC4BL6,FRSHC4BL6,FRBC4X4BL |
| Flammability Rating | 94V-0 |
| Material | PVC |
| Overall Height (In.) | 4.44 |
| Overall Height (mm) | 112.8 |
| Sub Brand | FiberRunner |
| Overall Length (ft.) | 6 |
| Overall Length (m) | 1.8 |
| Overall Width (In.) | 5.5 |
| Overall Width (mm) | 139.7 |
| Standards Met | UL Listed to 2024A,GR-63-CORE,RoHS Compliant |
| System Dimensions | 4x4 |
| Part Features | Fastest installations, Easy to maintain, System strength and Versatility |
Panduit - FR4X4BL6 - Package Information
| UPC | 07498345082 |
|---|---|
| Standard Package Quantity | 6 |
| Standard Package Volume (cf) | 0.6112 |
| Standard. Ctn. Quantity | 36 |
| Standard. Ctn. Volume (cf) | 3.6669 |
Panduit - FR4X4BL6 - Videos
| Video 1 | Click to View |
|---|---|
| Video 2 | Click to View |
| Video 3 | Click to View |
