Brand: Panduit
|
SKU:
225002
Panduit FR6ALB Bracket, Adjustable Ladder QuikLock for 4"; x 4"; And 6"; x 4"; FiberRunner
Regular price
$112.44
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit FR6ALB Bracket, Adjustable Ladder QuikLock for 4"; x 4...
Regular price
$112.44
Unit price
Description
Description
Panduit FR6ALB | Mounting Ladder Bracket for Fiber Pathways
The steel ladder bracket is used in cable routing systems to support the 6x4 and 4x4 FiberRunner Systems by directly attaching to any 0.375 inch L x 1.5 inch H (9.5mm x 38.1mm) or 0.375 inch L x 2 inch H (9.5mm x 50.8mm) ladder rack rails. It does not require a threaded rod. The ladder bracket includes hardware for mounting channel to bracket.
Panduit - FR6ALB - Features
- Adjustable to nine incremental positions from 4 Inch (101 mm) to 12 Inch (305 mm) above or below the ladder rack
- No threaded rod required
- The pre-assembled slide clamps enable fast assembly to channel
- Use 7/16 Inch nut driver on slide clamps
Specifications
Specifications
Panduit - FR6ALB - Product Categories
- Wire Routing, Management & Protection
- Fiber Routing Mounting Brackets & Hardware
Panduit - FR6ALB - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | FR6ALB |
| Item Description | Mounting Ladder Bracket for Fiber Pathways |
| Application | (1) The Fiberrunner 6X4 Routing System is a System of Channel, Fittings and Brackets Designed to Segregate, Route, and Protect Fiber Optic and High PerformanceCopper Cabling. (2) it is Suited for Data Center Applications |
| Product Type | Ladder Rack |
| Sub Brand | FiberRunner |
| Color | Black |
| For Use With | Fast Assembly to Channel |
| Includes | (1) Clasp Bracket, (2) Vertical Bracket Assembly, (2) "L" Bracket Assembly, (3) 5/16 Helical Spring Lockwashers, (3) 5/16-18x3/4 Hex Head Cap Screws |
| Material | Steel |
| Number of Pieces | 9 |
| Overall Height (In.) | 12.92 |
| Overall Height (mm) | 328.2 |
| Overall Length (In.) | 11.76 |
| Overall Length (mm) | 298.7 |
| Overall Width (In.) | 2.26 |
| Overall Width (mm) | 57.4 |
| Standards Met | UL Listed to 2024 Optical Fiber Cable Routing Assemblies Compliant with the Applicable Tests in Telcordia Gr-63-Core Network Equipment Building Systems Level 3, LP-CSISPEC-FR |
| System Dimensions | 4x4, 6x4 |
| Series Type | 4 x 4 and 6 x 4 FiberRunner Brackets |
Panduit - FR6ALB - Package Information
| UPC | 07498379924 |
|---|---|
| Standard Package Quantity | 1 |
| Standard Package Volume (cf) | 0.1201 |
| Standard. Ctn. Quantity | 10 |
| Standard. Ctn. Volume (cf) | 1.2006 |
Panduit - FR6ALB - Videos
| Video 1 | Click to View |
|---|
