Brand: Panduit
|
SKU:
699717
Panduit FRFWCSC12W4BL | Four Way Cross Cover | UPC - 07498311827
Regular price
$222.17
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit FRFWCSC12W4BL | Four Way Cross Cover | UPC - 07498311827
Regular price
$222.17
Unit price
Description
Description
Panduit Split Cover, 4-Way Cross, 12.96 in Length, 12.96 in Width, 2.78 in Height, Snap-On Mounting, For Use With: 12 x 4 in FiberRunner Routing System, ABS, Black
Features + Benefits
- Cover is attached to the fitting base with three hinge clips
- He hinge clips allow the hinged cover to rotate to a fully closed position and an open position greater than 90 deg
Panduit FRFWCSC12W4BL Key Specs
| Application | Segregate, Route, and Protect Fiber Optic and High Performance Copper Cabling. It is Suited for Data Center Applications where Cable is Routed from Distribution Areas to Equipment Cabinets or Racks. It is Used in Telco Central Offices to Route Fiber Optic |
| Product Type | Four Way Cross Cover |
| Sub Brand | FiberRunner |
| Bend Radius (In.) | 2 |
| Bend Radius (mm) | 50.8 |
| Channel Material | Rigid PVC |
| Color | Black |
| Fitting Type | Four Way Cross Cover with 4" Exits Cover |
| Fitting Material | ABS |
| Material | ABS |
| Overall Height (In.) | 2.78 |
| Overall Height (mm) | 70.6 |
| Overall Length (In.) | 12.96 |
| Overall Length (mm) | 329.2 |
| Overall Width (In.) | 21.25 |
| Overall Width (mm) | 539.8 |
| Standards Met | RoHS Complaint, UL Listed to 2024A Optical Fiber Cable Routing Assemblies Compliant with the applicable tests in Telcordia GR-63-CORE Network Equipment Building Systems Level 3 |
| System Dimensions | 12x4 |
Panduit FRFWCSC12W4BL Data Sheets
| Part Drawings | Part Drawings - PDF - FR12TB2412 | Download and View |
| Catalog Page Graphics | 24x4 Routing System Roadmap | Download and View |
