Panduit FRT12X4LYL | FiberRunner Horizontal Tee, 12x4, Yellow
Regular price
$325.50
Unit price
Brand: Panduit
|
SKU:
9992088
Regular price
$325.50
Unit price
Description
Description
Panduit FRT12X4LYL | FiberRunner Horizontal Tee, 12x4, Yellow
The FiberRunner 12x4 Horizontal Tee creates a 90° horizontal branch from straight horizontal runs. The horizontal tee provides versatility due to multiple spillout options that include spill-over fittings and the vertical tee which accepts a three-sided trumpet, transition to corrugated tubing and the FiberRunner System.
Panduit FRT12X4LYL Fiberrunner Horiz Tee Fitting12"x4" Yellow Lszhrohs Lszh
Specifications
Specifications
Panduit - FRT12X4LYL - Product Categories
- Wire Routing, Management & Protection
- Fiber Routing Bends, Crosses, Tees & End Caps
Panduit - FRT12X4LYL - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | FRT12X4LYL |
| Item Description | FiberRunner Horizontal Tee, 12x4, Yellow |
| Application | Data Centers and Telco Central Offices |
| Product Type | Tee Fitting |
| Sub Brand | FiberRunner |
| Bend Radius (In.) | 2 |
| Bend Radius (mm) | 50.8 |
| Color | Yellow |
| Fitting Type | Horizontal Tee |
| Fitting Material | PC/ABS |
| For Use With | 12x4 FiberRunner System |
| Material | PC/ABS |
| Overall Height (In.) | 4.22 |
| Overall Height (mm) | 107.2 |
| Overall Length (In.) | 18.09 |
| Overall Length (mm) | 459.5 |
| Overall Width (In.) | 22.5 |
| Overall Width (mm) | 571.5 |
| Standards Met | RoHS Compliant, UL Listed to 2024A Optical Fiber Cable Routing Assemblies Compliant with the applicable tests in Telcordia GR-63-CORE Network Equipment Building Systems Level 3 |
| System Dimensions | 12x4 |
| Components | FITTINGS |
| Finish | YELLOW |
| Material | PLASTIC |
| Type | CABLE ROUTING / WIRING DUCT |
| UNSPSC Code | 39131712 |
Panduit - FRT12X4LYL - Package Information
| UPC | 61305676378 |
|---|---|
| Standard Package Quantity | 1 |
| Standard Package Volume (cf) | 1.5970 |
| Standard Ctn. Quantity | 0 |
| Standard Ctn. Volume (cf) | 0.0000 |
Panduit - FRT12X4LYL - Videos
| Video 1 | Click to View |
|---|
